2010-00-246-0664
Ship Propulsion Shaft
2010002460664 002460664 YT215S43-2PC100
A shaft used to transmit to the propeller the torque generated by the main engine of a ship and also to transfer the propeller thrust to the thrust block. View more Ship Propulsion Shaft
May 2023
10
Marketplace 2010-00-246-0664
Request a Quotation from participating marketplace vendors
Related Documents 2010-00-246-0664 1+ Documents (More...)
Photo 1/2 2010-00-246-0664 Photo 2/2 - - 1.
United States (US) 4. 2010-00-246-0664 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 2010-00-246-0664
2010-00-246-0664 is a Ship Propulsion Shaft that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 2010-00-246-0664
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 2010-00-246-0664
- US Navy (N2H4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
Approved Sources 2010-00-246-0664
- Part Number
- Manufacturer
- Status
- YT215S43-2PC100
- Manufacturer
- 80064 - Naval Ship Systems Command (Active)
- Primary Buy
- Primary Buy
Datasheet 2010-00-246-0664
- Characteristic
- Specifications
- FIIG
- Specifications
- T08000
- After Bearing Sleeve Length [CPTP]
- 3.667 Feet Nominal
- After End Design [CPTC]
- Tapered
- After End Keyway [CPJG]
- Provided
- After Bearing Sleeve Outside Diameter [CPTH]
- 8.875 Inches Nominal
- Construction [ARQS]
- Solid
- Covering Location [CPTS]
- Surfaces Between Bearing Sleeve Covered
- Depth [AEJZ]
- 0.500 Inches Nominal
- Furnished Items And Quantity [AKYN]
- Propeller Nut,1; Propeller Key,1
- Forward Bearing Sleeve Length [CPTG]
- 4.000 Feet Nominal
- Forward Bearing Sleeve Outside Diameter [CPTF]
- 8.875 Inches Nominal
- Forward End Design [CPHM]
- Straight
- Forward End Diameter [CPHX]
- 8.750 Inches Nominal
- Forward End Keyway [CPJF]
- Provided
- Material [MATT]
- Steel, N, 49-S-2, Class B-S
- Usage Design [ALCD]
- Ytb215-229,253,264,277,290
- Keyway Depth [ABRV]
- 0.500 Inches Nominal
- Keyway Quantity [AEVE]
- 4
- Keyway Width [ABRR]
- 1.125 Inches Nominal
- Major Diameter [AAZR]
- 5.500 Inches Nominal
- Protective Covering Type [APZX]
- Rubber
- Quantity [NMBR]
- 2
- Outside Diameter [ABKV]
- 7.750 Inches Nominal
- Overall Length [ABHP]
- 27.198 Feet Nominal
- Thread Length [ABET]
- 6.000 Inches
- Thread Quantity [AZRW]
- 4 Per Inch
- Threaded After End [CPTD]
- Included
- Threaded Forward End [CPNF]
- Not Included
- Unit Type [APQB]
- Propeller Shaft Section
- Usage Location [BPJZ]
- Center
- Width [ABGL]
- 1.625 Inches Nominal
- Surface Finish [AGYE]
- Smooth Machined
- Taper Major Diameter [ABQB]
- 7.750 Inches Nominal
- Taper [CTKF]
- 1.000 Per Foot In Inches Nominal
- Taper Length [ABND]
- 1.459 Feet Nominal
Management Data 2010-00-246-0664
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 816.00
- NET PRICE 816.00
- R
Navy
- Cognizance:
- 7H
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 2010-00-246-0664
Freight Information 2010-00-246-0664
2010-00-246-0664 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 129930. A Sub NMFC of X. It has a NMFC Description of SHAFTS,TAIL SHIPS PROPELLER SHAFT. 2010-00-246-0664 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 2010-00-246-0664 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 65760 which rates the freight between FCL and LCL. 2010-00-246-0664 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 810 for ocean manifesting and military sealift. 2010-00-246-0664 is not classified as a special type of cargo when transported by water. 2010-00-246-0664 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
