1740-01-031-5868

Ground Handling Trailer

1740010315868 010315868 748500 76H05000 1740PL0739807 10143576

A trailer designed primarily for transporting aircraft components, munitions, cradles and the like. May include rails. For trailers with a mechanical or hydraulic lifting device, see TRAILER (1), LIFT, GROUND HANDLING. View more Ground Handling Trailer

Managed by United States

NSN Created on 26 Nov 1976

Data Last Changed
May 2023

NATO Update Count
52

NATO Data Quality

1740-01-031-5868 TRAILER,GROUND HANDLING 1740010315868 010315868 1/1 — 1740-01-031-5868 Photo 1/1

Marketplace 1740-01-031-5868

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

748500 TRAILER,GROUND HANDLING 2 EA NS

Subscribe to View Vendor Details...

74850-#0 TRAILER,GROUND HANDLING 1 EA NS

Subscribe to View Vendor Details...

1740-01-031-5868 TRAILER,GROUND HANDLING 5 EA NS

Subscribe to View Vendor Details...

748500 TRAILER,GROUND HANDLING 5 EA NS

Updated Every Day

1740-01-031-5868 RQST NE

Updated Every Day

1740-01-031-5868 RQST

Updated Every Day

1740-01-031-5868 RQST NE

Restrictions 1740-01-031-5868

IUID Required

1740-01-031-5868 is a Ground Handling Trailer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item where key elements must be removed and destroyed to prevent this item being restored or repaired. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1740-01-031-5868

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1740-01-031-5868

US Air Force (FGG4)
Effective Date:: 1 Sep 2000
Former MOE Rule:: FEE4; AMC 1 AMSC G AMSC X IMC D DSOR 99

US Navy (NMGS)
Effective Date:: 1 Sep 2000
Former MOE Rule:: NMES
Supplementary Receivers:: GG; AMC 1 AMSC G AMSC 1 IMC D DSOR 00

Austria (WB01)
Effective Date:: 1 Feb 2005

Finland (WF01)
Effective Date:: 1 Jun 2009

Hungary (WH01)
Effective Date:: 1 Aug 2008

Poland (WP01)
Effective Date:: 1 Jun 2011

Czech Republic (WZ01)
Effective Date:: 1 Feb 2006

Brazil (YA01)
Effective Date:: 1 Dec 2012

Spain (YB01)
Effective Date:: 1 Apr 1991

Israel (YD01)
Effective Date:: 1 Jul 2016

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Australia (ZA01)
Effective Date:: 1 Apr 1991

Belgium (ZB01)
Effective Date:: 1 Apr 1991

Canada (ZC01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Philippines (ZM01)
Effective Date:: 1 Feb 2015

Netherlands (ZN01)
Effective Date:: 1 Dec 1996

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Jul 2001

Norway (ZT01)
Effective Date:: 1 Jul 2005

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Dec 1995

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Oct 2013

Approved Sources 1740-01-031-5868

Part Number
Manufacturer
Status
748500: 18894 - Air Armament Center/ En (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
76H05000: 12339 - Drs Training & Control Systems, Llc (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
1740PL0739807: 9009H - Jednolity Indeks Materialowy - (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9
10143576: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 1740-01-031-5868

Characteristic
Specifications
FIIG: T277-A
Functional Classification [FCLS]: Hh-2.8
Reference Data And Literature [RDAL]: T.O. 35D3-2-27-11
Relationship To Similar Equipment [RTSE]: 1740-00-944-8321,1740-00-689-2640,1740-689-2616,1740-00-342-1710
Overall Height [ABKW]: 32.000 Inches Nominal
Overall Length [ABHP]: 126.000 Inches Nominal
Overall Width [ABMK]: 84.000 Inches Nominal
Parking Brakes [BPGN]: Included
Special Features [FEAT]: Stype Of Control - Manual; Electrical System - 2 Tail Lamps, 1 Black Out, 1 Stop; Braking System Type - 4 Wheel Hydraulic; Suspension Type - Leaf Type Springs; Maximum Towing Speed - 10 Mph Off Road; Maximum Towing Speed - 20 Mph Unloaded Highway; Body Type - Aluminum Flat Deck W/Hinged Center Section; Capacity - 5500 Lbs; Transportability - Towed, Telescopic Hitch; Tire Size - 7.5 X 7.5; Tire Type - 10 Ply; Tire Thread 73 In. Track; Steering Type - Towbar And Auto Type Tie Rods
Type/Model Designation [TMDN]: Mhu-141/M
Wheel Quantity [AGDH]: 4
Specific Use [ANTN]: Designed For Temporary Storage And Transportation Of A Variety Of Munitions And Other Stores
Tire Type [ALRE]: Pneumatic

Management Data 1740-01-031-5868

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Feb 2020: Department of the Air Force (DF); EA; Subscribe; 1
Aug 2006: Department of the Navy (DN); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): L; G; Replaces 1740-00-342-1710; AAA
Department of the Air Force (DF): L; Dod I&S Family Master Nsn - - -; AAB

Navy

Cognizance:

6R: Bypass

Special Material ID:

SX: Special Aircraft and Engine Tool and Support Equipment/Parts

Issue, Repair, Requisition Restriction Code:

BS: Submit/refer requisitions to NAVICP PHIL

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Similar Supply Items to 1740-01-031-5868

Freight Information 1740-01-031-5868

1740-01-031-5868 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 189140. A Sub NMFC of E. It has a NMFC Description of VEHICLES:FRT CARTS/TRUCKS ETC SUB5. 1740-01-031-5868 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1740-01-031-5868 is rated as class 125 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 92900 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 891 for ocean manifesting and military sealift. 1740-01-031-5868 is classified as a Protected/Sensitive Non-Hazardous Non-ESD Commodity when transported by water. 1740-01-031-5868 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 1740-01-031-5868

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 140.0" H x 84.0" W x 96.0" L; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 140.0" H x 84.0" W x 96.0" L; --; --; Preservative Coating Only; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Preserve with Normal Operating Lubricant; No Requirement; No Requirement; Not Applicable; No Requirement; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement

Contracting Technical Data File (CTDF) 1740-01-031-5868 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:

Subscribe
View CTDF

Subscribe to View CTDF Details...
