1730-01-370-4268
Aircraft Maintenance Platform
1730013704268 013704268 50000-000-00
An item of equipment with small floored area(s) supported by scaffolding of metal or wood framework, either portable or stationery. For use in repairing, cleaning, installing and inspection of property, machinery and equipment above the general floor level. See also SERVICING PLATFORM, SELF-PROPELLED AND SERVICING PLATFORM, TRUCK MOUNTED. View more Aircraft Maintenance Platform
August 2023
13
Marketplace 1730-01-370-4268
Request a Quotation from participating marketplace vendors
Related Documents 1730-01-370-4268 4+ Documents (More...)
United States (US) 4. 1730-01-370-4268 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 1730-01-370-4268
Aircraft Maintenance Platform 1730013704268 Documents 1730-01-370-4268 1+ Documents ( More... )
0100 Sub Plate Valve 1; 09990 21110-54-02-0200 Solenoid Valve 1End Item Identification [AGAV] 1730-01-370-4268
Restrictions 1730-01-370-4268
IUID Required
1730-01-370-4268 is a Aircraft Maintenance Platform that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1730-01-370-4268
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1730-01-370-4268
- US Air Force (FGG4)
- Effective Date:
- 1 Sep 2000
- Former MOE Rule:
- FEE4
- Australia (ZA01)
- Effective Date:
- 1 Sep 2006
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Feb 2014
Approved Sources 1730-01-370-4268
- Part Number
- Manufacturer
- Status
- 50000-000-00
- Manufacturer
- 2W888 - Mct Industries, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 1730-01-370-4268
- Characteristic
- Specifications
- FIIG
- Specifications
- T361-J
- Adjustability [APCS]
- Adjustable
- Adjustment Method [AREG]
- Hydraulic
- Working Level Dimension [CHJH]
- 36 Ft Elevated Height
- Maximum Overall Height [CHQR]
- 122.000 Inches
- Rated Load Capacity [CNTJ]
- 2000.0 Pounds
- Special Features [FEAT]
- Height Is With Platform Elevated; Width Is With Outrigger Extended; Width With Outrigger Retracted 13.1 Ft; Height To Platform (Lowered) 6.7 Ft; Platform Width 8 Ft; Platform Length 15 Ft 5 Inches; Platform Extension 8 Ft; Weight 14,500 Lbs; Gradeability 25%; Self Propelled Speed (Lowered) 3 Mph, (Elevated) 0.3 Mph; Max Towing Speed 15 Mph; Outside Turning Circle 40.25 Ft; Max Side Wind (Elevated) 15 Mph; Prefered Fuel Diesel No. 2, Alternative Fuel Jp4, Jp5, Jp8; Tires 12-16.5 10 Ply Rated Highway Type; Fuel Capacity 18 Gal; Includes Davit; Davit Load Capacity 250 Lbs At Outermost Position, 500 Lbs At Mid Position
- Functional Description [FTLD]
- Diesel Powered Platform, Self Propelled, Hydraulically Operated; Consists Of A Box Tube Chassis Frame Supporting A Pantographing Steel Scissors Lift Mechanism That Extends Upward, Raising A Work Surface Platform; The Platform May Be Extended Forward To Any Height; May Be Driven Or Towed, Including Being Driven While Elevated; Designed To Be Used In Class I Div 2 Group D Hazardous Environments
- Relationship To Similar Equipment [RTSE]
- Similar To Nsn 1730-01-118-5451 Plus Engineering Change Proposals
- Reference Data And Literature [RDAL]
- T.O. 35A4-2-67-1
- Part Name Assigned By Controlling Agency [CXCY]
- Maintenance Platform,Split Deck,Diesel
- Working Platform Quantity [CHJJ]
- 1
- Floor Material [AQJL]
- Steel
- Rolling Element Type And Quantity [AYJW]
- 4 Wheel
- Locking Device [AMDA]
- Included
- Ladder [CHJL]
- Not Included
- Platform Safety Guard [CHJM]
- Included
- Safety Guard Type [CHQN]
- Adjustable
- Maximum Overall Length [CHQP]
- 201.000 Inches
- Maximum Overall Width [CHQQ]
- 157.000 Inches
Management Data 1730-01-370-4268
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Jul 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Jun 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2023
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Dec 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 1730-01-557-4560
- 3
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-01-605-5401
- J
Air Force
- Budget:
- A
- 57X3010 - Common Aircraft Ground Support Equipment
- Aggregation Code:
- RN
- GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC)
- Price Validation Code:
- P
- The current standard price is the initial negotiated provisioned price.
This is the price paid by DoD for the item as the result of price negotiation of the Provisioned Item Order (PIO) or other initial negotiated price.
ZOP or Standard Price challenges are permissible but should be supported with adequate justification.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
NATO Stock Numbers Related to 1730-01-370-4268
Freight Information 1730-01-370-4268
1730-01-370-4268 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 1730-01-370-4268 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1730-01-370-4268 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 1730-01-370-4268 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1730-01-370-4268 is classified as a Corrosive Material, UN Class 8, when transported by water. 1730-01-370-4268 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
