1730-00-921-6560
Rail Type Trailer
1730009216560 009216560 MILT26225 4000A BP4000A
A wheeled trailer supporting one or more pairs of horizontal parallel rails or tracks with or without mechanical or hydraulic operated lifting devices. Designed for transferring and transporting engine cradles, missile component cradles, and the like, from rail type maintenance stands and other rail type transporting and storage vehicles. The trailer rails mate with the rails of the maintenance stands, and the like, for rolling the cradles from one to the other. Excludes rail type trailers having attached cradles or additionalequipment designed for specific items. View more Rail Type Trailer
May 2023
20
Marketplace 1730-00-921-6560
Request a Quotation from participating marketplace vendors
Related Documents 1730-00-921-6560 5+ Documents (More...)
United States (US) 4. 1730-00-921-6560 Marketplace Restrictions Approved Sources Datasheet Management
TRAILER,RAIL TYPE 116 EA NS Request Quotation Subscribe to View Vendor Details... 4000A TRAILER,RAIL
ETU8E TRAILER,RAIL TYPE 2 EA NS Request Quotation 4000A TRAILER,RAIL TYPE 1 EA NS Request Quotation Updated
5+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5925/fr 5925-14-334-2995 Ecran Dgsm 4000A
Sep 1984 1320-17-116-4441 https//www.nsnlookup.com /fsg-59/fsc-5925/fr 5925-14-334-2995 Ecran Dgsm 4000A
Storage Battery 6140142516425 142516425,4000A View Vendor Details... 4000A PYROMETER,INDICATING how
to enable JavaScript in your web browser . 6625-99-894-8744Ammeter6625998948744 998948744EQ96 0-4000A
Restrictions 1730-00-921-6560
IUID Required
1730-00-921-6560 is a Rail Type Trailer that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 1730-00-921-6560
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1730-00-921-6560
- US Air Force (FGG4)
- Effective Date:
- 1 Apr 2001
- Former MOE Rule:
- FEE4
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 1730-00-921-6560
- Part Number
- Manufacturer
- Status
- 4000A
- Manufacturer
- 29731 - Gardner Denver Water Jetting (Active)
- Primary Buy
- Primary Buy
- MILT26225
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- BP4000A
- 17025 - Boston Pneumatics Inc Texas Division (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 1730-00-921-6560
- Characteristic
- Specifications
- FIIG
- Specifications
- A23900
- Departure From Cited Designator [ZZZX]
- The Mfr Data
- General Characteristics Item Description [TEXT]
- 8000 Lg Rated Capacity; Rail Data,1 Pair Of Rails,Mounted On Trailer From Front To Rear,Elevating,Hydraulic Operated,152 In. Lg,3.33 In. Rail Roller Surface Flange,48 In. Rail Spacing C To C,89 In. H From Ground; Drawbar Data,Pole Type,Telescoping,W/Coupler Drawbar Ring; W/O Service Brakes; W/Parking Brakes; W/O Pintle Assembly,Towing; W/Auxiliary Support Legs; No Addtional Equipment Furnished
- Nondefinitive Spec/Std Data [ZZZT]
- Etu8e Type
Management Data 1730-00-921-6560
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Dec 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- 3
- Reversal Of Phrase Code S 1730-01-508-3156
- 3
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-00-294-3397
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-00-528-6616
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-00-563-1339
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-00-706-9233
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-00-789-1249
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-01-473-8882
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-01-569-1682
- J
- Department of the Air Force (DF)
- L
- J
- Interchangeable With 1730-01-632-2207
- J
Air Force
- Budget:
- M
- 57X3080 - Other Base Maintenance and Support Equipment
- Aggregation Code:
- RN
- GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC)
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - U
- Reparable. Condemn at Intermediate. AF Equipment Management System (AFEMS).
NATO Stock Numbers Related to 1730-00-921-6560
Freight Information 1730-00-921-6560
1730-00-921-6560 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 157520. A Sub NMFC of X. It has a NMFC Description of PLATFORMS AIRCRAFT CARGO SHIPNG NOI. 1730-00-921-6560 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05380 which rates the freight between FCL and LCL. 1730-00-921-6560 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1730-00-921-6560 is not classified as a special type of cargo when transported by water. 1730-00-921-6560 is not a consolidation, but exceeds 84" in at least one dimension. It may not be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1730-00-921-6560
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 158.0" H x 86.0" W x 42.0" L
- --
- --
- --
- --
- 158.0" H x 86.0" W x 42.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- --
- --
- --
- --
- Center of balance
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
