1680-00-245-1833
Linear Electro-Mechanical Actuator
1680002451833 002451833 AL2432M3-1 114VS800-3
A self-contained power transmitting device designed to convert electrical energy into controlled mechanical force, in the form of linear (straight line) mechanical movement. Comprised of an electrical motor(s), gear box(es), screwjacks, limit switch(es), and such accessories as required for the specific moving and positioning of other components. Excludes hydraulic and pneumatic cylinders and screwjacks. View more Linear Electro-Mechanical Actuator
June 2023
16
Marketplace 1680-00-245-1833
Request a Quotation from participating marketplace vendors
Related Documents 1680-00-245-1833 2+ Documents (More...)
Photo 1/2 1680-00-245-1833 Photo 2/2 - - 1.
United States (US) 4. 1680-00-245-1833 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 1680-00-245-1833
1680-00-245-1833 is a Linear Electro-Mechanical Actuator This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 1680-00-245-1833
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1680-00-245-1833
- US Army (A702)
- Effective Date:
- 1 Apr 1991
- Spain (YB01)
- Effective Date:
- 1 Feb 1994
- Singapore (YJ01)
- Effective Date:
- 1 May 1996
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 2006
Approved Sources 1680-00-245-1833
- Part Number
- Manufacturer
- Status
- AL2432M3-1
- Manufacturer
- 12511 - Simmonds Precision Products Inc (Active)
- Primary Buy
- Primary Buy
- 114VS800-3
- 77272 - The Boeing Company (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 1680-00-245-1833
- Characteristic
- Specifications
- FIIG
- Specifications
- A30500
- Duty Cycle [AKPS]
- Continuous
- Body Height [ADAU]
- 2.500 Inches Maximum
- Body Width [ADAT]
- 3.470 Inches Maximum
- Compression Load Rating [AWTC]
- 400.0 Pascal Grams Static
- Compression Load Rating [AWTC]
- 50.0 Pascal Grams Operating
- Current Type [ACDC]
- Ac
- Environmental Protection [ADZC]
- Dustproof And Moisture Proof And Vibration
- Frequency In Hertz [FREQ]
- 380.0 And 450.0
- Maximum Operating Altitude Rating [AKAE]
- 25000.0 Feet
- Mounting Facility [AZGM]
- Rod End
- Limit Switch Control [AWQN]
- Not Included
- Rated Stroke Velocity [AWTE]
- 0.480 Inches Per Second And 1.080 Inches Per Second
- Phase [FAAZ]
- Single
- Voltage In Volts [ELEC]
- 108.0 And 126.0
- Stroke Length [AMWL]
- 5.730 Inches Minimum And 5.930 Inches Maximum
- Tension Load Rating [AWTA]
- 400.0 Pounds Nominal Static Err-100
- Tension Load Rating [AWTA]
- 50.0 Pounds Nominal Operating Err-100
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit And 160.0 Deg Fahrenheit
Management Data 1680-00-245-1833
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Army (DA)
- L
- R
- Refer To Net Price 11550.00
- NET PRICE 11550.00
- R
Army
- Materiel Category and Inventory Manager:
- H
- Aircraft, Air Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- BK
- Rotary Wing Aircraft
CH-47
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 1680-00-245-1833
Freight Information 1680-00-245-1833
1680-00-245-1833 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 011790. A Sub NMFC of Z. It has a NMFC Description of AIRCRAFT PARTS NOI. 1680-00-245-1833 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 04720 which rates the freight between FCL and LCL. 1680-00-245-1833 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1680-00-245-1833 is not classified as a special type of cargo when transported by water. 1680-00-245-1833 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1680-00-245-1833
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 12.0" H x 3.2" W x 2.5" L
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 14.0" H x 4.5" W x 4.5" L
- --
- --
- --
- Any Suitable Process
- 14.0" H x 4.5" W x 4.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
