1650-01-455-3683
Aircraft Hydraulic Swivel Joint
1650014553683 014553683 AE70706G 74-690133-106
A mechanical fluid passage joint designed for linkage of aircraft rigid hydraulic lines and components subject to pivotal, linear, or rotational position changes.The device allows two-directional flow of high pressure fluid and permits single plane rotation upon its axis.It may also allow for angular movement.Excludes SWIVEL JOINT, PIPE; and SWIVEL JOINT, TUBE. View more Aircraft Hydraulic Swivel Joint
November 2023
4
Product Information 1650-01-455-3683
Hydraulic System Swivel
Used on Boeing F/A-18E/F “Super Hornet” Strike Fighter
The F/A-18E/F incorporates six different dual passage swivels in the main landing gear system and wing fold system. The swivels are used to provide rotational flexibility during extension and retraction of the gears and folding of the wings for aircraft stowage on board aircraft carriers. The complex swivels are made to withstand the demanding corrosive environment found on sea-based applications, of which two are qualified for 5,000 psig (34,500 kPa).
Marketplace 1650-01-455-3683
Request a Quotation from participating marketplace vendors
Related Documents 1650-01-455-3683 3+ Documents (More...)
United States (US) 4. 1650-01-455-3683 Marketplace Restrictions Approved Sources Datasheet Management
Marketplace 1650-01-455-3683 Need Help?
Restrictions 1650-01-455-3683
1650-01-455-3683 is a Aircraft Hydraulic Swivel Joint that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-01-455-3683
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-01-455-3683
- US Navy (N9BG)
- Effective Date:
- 1 Sep 2012
- Former MOE Rule:
- N1R5
- Supplementary Collaborators:
- GGKEGT
- Australia (ZA01)
- Effective Date:
- 1 Aug 2008
Approved Sources 1650-01-455-3683
- Part Number
- Manufacturer
- Status
- AE70706G
- Manufacturer
- 00624 - Eaton Aeroquip Llc (Active)
- Primary Buy
- Primary Buy
- 74-690133-106
- 76301 - The Boeing Company (Active)
- Secondary Buy
- Secondary Buy
Datasheet 1650-01-455-3683
- Characteristic
- Specifications
- FIIG
- Specifications
- A080B0
- End Item Identification [AGAV]
- Preprovisioning Support Navicp Is Poe
Weapon Systems (WSDC) 1650-01-455-3683
DLA Procurement Analysis 1650-01-455-3683
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 1650-01-455-3683
Navy
- Cognizance:
- 3B
- Special Material ID:
- QE
- Fighter Aircraft - First (F18 E/F)
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-01-455-3683
Freight Information 1650-01-455-3683
1650-01-455-3683 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 011790. A Sub NMFC of Z. It has a NMFC Description of AIRCRAFT PARTS NOI. 1650-01-455-3683 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 04720 which rates the freight between FCL and LCL. 1650-01-455-3683 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-01-455-3683 is not classified as a special type of cargo when transported by water. 1650-01-455-3683 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 1650-01-455-3683 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
