1650-01-375-2510
Servocylinder
1650013752510 013752510 123SCH145-13 127400-13
A hydraulically or pneumatically powered actuating cylinder with provisions for directional control (positioning) in direct relation with a primary control of comparatively low level force. The primary control input to the servocylinder may be mechanical and/or electrical. View more Servocylinder
May 2023
11
Marketplace 1650-01-375-2510
Request a Quotation from participating marketplace vendors
Related Documents 1650-01-375-2510 2+ Documents (More...)
Photo 1/3 1650-01-375-2510 Photo 2/3 NSN 1650-01-375-2510 (Identification) 3/3 - - - 1.
United States (US) 4. 1650-01-375-2510 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 1650-01-375-2510
IUID Required
1650-01-375-2510 is a Servocylinder This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-01-375-2510
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-01-375-2510
- US Navy (N2R4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
- France (ZF01)
- Effective Date:
- 1 Apr 1996
Approved Sources 1650-01-375-2510
- Part Number
- Manufacturer
- Status
- 127400-13
- Manufacturer
- 59211 - Parker-Hannifin Corporation (Active)
- Primary Buy
- Primary Buy
- 127400-13
- 93835 - Parker-Hannifin Corp (Active)
- Secondary Buy
- Secondary Buy
- 127400-13
- 82106 - Parker-Hannifin Corporation (Active)
- Secondary Buy
- Secondary Buy
- 123SCH145-13
- 26512 - Northrop Grumman Systems Corporation (Active)
- Obsolete Drawing
- Obsolete Drawing
- 123SCH145-13
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 1650-01-375-2510
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Body Material [AAFZ]
- Steel, Corrosion Resisting
- Bore Diameter [ABXV]
- 1.813 Inches Nominal
- Compressed Length [AMQZ]
- 22.860 Inches Nominal
- Design Characteristics [CKSD]
- Double Acting Tandem Cylinder
- Extended Length [ATEM]
- 28.360 Inches Nominal
- First Piston Rod End Style [CKSF]
- Bearing Type
- End Item Identification [AGAV]
- Acft Model E-2C
- Integral Valve Operation Method [CKRM]
- Hydraulic
- Piston Rod End Similarity [CLLP]
- Not Identical
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Nominal
- Second Piston Rod End Style [CLLQ]
- Bearing Type
- Special Features [FEAT]
- Actuator Body Assembly (Lh)
- Temp Rating [ABJH]
- 274.0 Deg Fahrenheit
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit
Management Data 1650-01-375-2510
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 51876.00
- NET PRICE 51876.00
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- BE
- Special Electronic Aircraft (E2/C2)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-01-375-2510
Freight Information 1650-01-375-2510
1650-01-375-2510 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of B. It has a NMFC Description of MACHINERY/MACHINES NOI SUB 2. 1650-01-375-2510 is rated as class 92.5 when transported by Less-Than Truckload (LTL) freight. 1650-01-375-2510 is rated as class 92.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 1650-01-375-2510 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-01-375-2510 is not classified as a special type of cargo when transported by water. 1650-01-375-2510 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-01-375-2510
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Unheated General Purpose
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 31.0" H x 16.0" W x 16.0" L
- --
- --
- --
- Any Suitable Process
- 31.0" H x 16.0" W x 16.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Vendor's Protective Grease or Oil Coating
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- 1/2 inch thick
- NAVICP Drawing No. 15450, Modular Reusable Container for Packaging Depot Level Repairables
- Method 50
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
