1650-00-931-5207
Fluid Filtering Disk
1650009315207 009315207 71582
A flat, circular, replaceable device, with or without a centrally located hole, designed to remove solid particles from fluids ranging in density from heavy liquids to gases. The removal of particles is accomplished by porous, fibrous or shredded material (metallic or non-metallic) which retains the solid particles in the fluid passing through it. It may be encased and used as a single item or stacked to form a fluid filter element. Excludes DISK, SOLID, PLAIN; DIAPHRAGM (as modified); STRAINER ELEMENT, SEDIMENT; and WIRE FABRIC. View more Fluid Filtering Disk
May 2023
2
Marketplace 1650-00-931-5207
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-931-5207 5+ Documents (More...)
United States (US) 4. 1650-00-931-5207 Marketplace Restrictions Approved Sources Datasheet Management
NE FedMall Updated Every Day 1650-00-931-5207 RQST NE Updated Every Day 1650-00-931-5207 RQST Updated
enable JavaScript in your web browser . 6770-15-236- 2019Videocassettaoltre6770152362019 152362019CC 71582
Fluid Filtering Disk 1650009315207 009315207 Videocassettaoltre 6770152362019152362019 enable JavaScript
/www.nsnlookup.com /fsg-53/fsc-5360/us 5360-00-526-3605 Compression Helical Spring 5360005263605 3-71582
375-5375 Torsion Helical Spring 5360143755375,71582 2019Videocassettaoltre6770152362019 152362019CC 71582
enable JavaScript in your web browser . 5120-15-175-9469Chiave Ad Occhiello5120151759469 151759469 71582
/www.nsnlookup.com /fsg-51/fsc-5120/it 5120-15-175-9469 Chiave Ad Occhiello 5120151759469151759469 71582
www.nsnlookup.com /fsg-51/fsc-5120/it 5120-15- 175-9469 Chiave Ad Occhiello 5120151759469151759469 71582
152362019CC 71582 https//www.nsnlookup.com https//www.nsnlookup.com /fsg-53/fsc-5360/fr 5360-14-375-
Restrictions 1650-00-931-5207
1650-00-931-5207 is a Fluid Filtering Disk that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-00-931-5207
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-931-5207
- US Navy (N9BG)
- Effective Date:
- 1 Aug 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- KE
Approved Sources 1650-00-931-5207
- Part Number
- Manufacturer
- Status
- 71582
- Manufacturer
- 11599 - Triumph Engine Control Systems Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 1650-00-931-5207
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Body Diameter [ABPM]
- 0.764 Inches Minimum And 0.770 Inches Maximum
- Body Inside Diameter [ADAS]
- 0.450 Inches Minimum And 0.460 Inches Maximum
- Body Thickness [ADPR]
- 0.029 Inches Minimum And 0.035 Inches Maximum
- Filtering Media Design [CRXW]
- Mesh Single Filtering Media Response
- Fsc Application Data [ZZZV]
- Fuel Control,Acft
- Material [MATT]
- Steel Corrosion Resisting Filtering Medium
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon
- Style Designator [STYL]
- Round (Basically Flat W/ Opening)
DLA Procurement Analysis 1650-00-931-5207
Management Data 1650-00-931-5207
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 1650-00-931-5207
Freight Information 1650-00-931-5207
1650-00-931-5207 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 1650-00-931-5207 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 1650-00-931-5207 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 586 for ocean manifesting and military sealift. 1650-00-931-5207 is not classified as a special type of cargo when transported by water. 1650-00-931-5207 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 1650-00-931-5207 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Y
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
