1650-00-764-4694
Fluid Filter
1650007644694 007644694 MIL-F-8815/24 7586589 AC9416F-16Y1 M8815/24 AC9416F16L AC9416F16 10106069
A filter having inlet and outlet connections and designed to be connected in a pipe, tube or hose line. For spin-on, base-mounted filtering devices with integral outer casings, see FILTER ELEMENT, FLUID. Excludes AIR CONDITIONER. View more Fluid Filter
Managed by United States
NSN Created on 7 Oct 1972
Data Last Changed
November 2023
November 2023
NATO Update Count
20
20
NATO Data Quality
Marketplace 1650-00-764-4694
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-764-4694 1+ Documents (More...)
MIL-F-8815/24 7586589 AC9416F-16Y1 M8815/24 AC9416F16L AC9416F16 10106069 A filter having inlet and
Photo 1/2 NSN 1650-00-764-4694 (Identification) 2/2 - - 1.
NS Request Quotation Updated Every Day 1650-00-764-4694 RQST NE Updated Every Day 1650-00-764-4694 RQST
Photo 1/2 NSN 1650-00-764-4694 (Identification) 2/2 - - 1.
NS Request Quotation Updated Every Day 1650-00-764-4694 RQST NE Updated Every Day 1650-00-764-4694 RQST
Restrictions 1650-00-764-4694
1650-00-764-4694 is a Fluid Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-00-764-4694
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-764-4694
- US Air Force (FXGG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- FXCX
- US Navy (N9BG)
- Effective Date:
- 1 Jul 2006
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- GTKE
- Finland (WF01)
- Effective Date:
- 1 Feb 2009
- Spain (YB01)
- Effective Date:
- 1 Dec 2001
- Australia (ZA01)
- Effective Date:
- 1 Nov 2001
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 1650-00-764-4694
- Part Number
- Manufacturer
- Status
- M8815/24
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-F-8815/24
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 7586589
- 05228 - Pti Technologies Inc. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AC9416F-16Y1
- 18350 - Pall Aeropower Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- AC9416F16L
- 18350 - Pall Aeropower Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- AC9416F16
- 18350 - Pall Aeropower Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10106069
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Datasheet 1650-00-764-4694
- Characteristic
- Specifications
- FIIG
- Specifications
- A24000
- Distance From Bottom Of Body To Center Of Inlet [CSKY]
- 5.485 Inches Nominal
- Drop Pressure [ADNP]
- 10.0 Pounds Per Square Inch
- Body Height [ADAU]
- 7.660 Inches Nominal
- Body Length [ADAQ]
- 2.750 Inches Nominal
- Body Width [ADAT]
- 1.812 Inches Nominal
- Design Type [APGF]
- Nonreusable
- Features Provided [CBBL]
- Differential Pressure Indicator
- Filtering Element Quantity [CCZM]
- 1
- Filtering Media Design [CRXW]
- Corrugated Single Filtering Media Response
- Filtering System For Which Designed [CXZX]
- Full Flow
- Filtration Rating In Microns [ADNH]
- 5.0 Absolute
- First Discharge Connection Relationship To Intake Connection [CSJR]
- Identical To First Intake Connection
- First Intake Connection Type [CRXZ]
- Threaded Internal Tube Head Side
- First Intake Nominal Thread Size [CTGK]
- 0.437 Inches
- First Intake Thread Class [CWNZ]
- 3B
- First Intake Thread Direction [CXPF]
- Right-Hand
- First Intake Thread Series Designator [CTDY]
- Unjf
- Material [MATT]
- Steel Corrosion Resisting Body
- Material [MATT]
- Steel Corrosion Resisting Filtering Medium
- Maximum Operating Pressure [CQGM]
- 3000.0 Pounds Per Square Inch
- Media For Which Designed [MEDA]
- Fuel/Oil, Hydrocarbon
- Mounting Type [AAXX]
- Inlet Connection Head Side And Outlet Connection Head Side
- Style Designator [STYL]
- Tee Type (Hydraulic)
- Temp Rating [AZKQ]
- -65.0 Deg Fahrenheit Minimum And 275.0 Deg Fahrenheit Maximum
Weapon Systems (WSDC) 1650-00-764-4694
DLA Procurement Analysis 1650-00-764-4694
- Last Stock Position:
- 6 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 1650-00-764-4694
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 1650-00-764-4694
4330-99-852-0735 2910-12-367-3651 4330-25-150-9110 2940-98-204-5651 4330-12-377-4992 6515-12-381-7567 4330-12-381-0125 2910-13-119-5435 4330-99-709-1442 4330-99-612-6237 4330-12-360-4953 2910-22-619-5095 4330-17-115-4952 2910-12-368-6759 4310-98-855-0816 4130-12-366-6736 4330-12-343-9896 1650-99-841-9689
Freight Information 1650-00-764-4694
1650-00-764-4694 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 069100. A Sub NMFC of Z. It has a NMFC Description of FILTERS:CARTRIDGES/ELEMENTS. 1650-00-764-4694 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 21275 which rates the freight between FCL and LCL. 1650-00-764-4694 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 677 for ocean manifesting and military sealift. 1650-00-764-4694 is not classified as a special type of cargo when transported by water. 1650-00-764-4694 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-00-764-4694
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Non-Metallic Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 999.9" H x 99.9" W x 999.9" L
- --
- --
- --
- Any Suitable Process
- 999.9" H x 99.9" W x 999.9" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
Procurement History 1650-00-764-4694 16 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE4A722F2399
- 18 Nov 2021
- Subscribe
- 135
- Subscribe
- Subscribe
- Subscribe
- SPE4A722F2399
- 18 Nov 2021
- Subscribe
- 135
- Subscribe
- Subscribe
- Subscribe
- SPE4A719F2163
- 19 Nov 2018
- Subscribe
- 1852
- Subscribe
- Subscribe
- Subscribe
- SPE4A717D03900001
- 13 Sep 2017
- Subscribe
- 1101
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D01100018
- 16 Nov 2014
- Subscribe
- 543
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D01100017
- 15 Oct 2014
- Subscribe
- 8
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D01100016
- 14 Oct 2014
- Subscribe
- 864
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110001501
- 10 Aug 2014
- Subscribe
- 306
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110001401
- 06 Aug 2014
- Subscribe
- 10
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110001301
- 05 Aug 2014
- Subscribe
- 864
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110001201
- 30 Jul 2014
- Subscribe
- 859
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110001002
- 27 Jan 2014
- Subscribe
- 11
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110000902
- 05 Nov 2013
- Subscribe
- 25
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110000801
- 13 Jun 2013
- Subscribe
- 407
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110000701
- 11 Apr 2013
- Subscribe
- 432
- Subscribe
- Subscribe
- Subscribe
- SPE4A712D0110000601
- 29 Mar 2013
- Subscribe
- 457
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 1650-00-764-4694 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
