1650-00-529-0623
Hydraulic Motor
1650005290623 005290623 MF10-711-30S335-4
A mechanical device designed to convert the energy of fluid pressure to rotary motion. View more Hydraulic Motor
May 2023
16
Marketplace 1650-00-529-0623
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-529-0623 5+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Updated Every Day 1650-00-529-0623
RQST NE Updated Every Day 1650-00-529-0623 RQST Updated Every Day 1650-00-529-0623 RQST NE Restrictions
Restrictions 1650-00-529-0623
1650-00-529-0623 is a Hydraulic Motor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 1650-00-529-0623
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-529-0623
- Greece (ZU)
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 1650-00-529-0623
- Part Number
- Manufacturer
- Status
- MF10-711-30S335-4
- Manufacturer
- 62983 - Eaton Aerospace, Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 1650-00-529-0623
- Characteristic
- Specifications
- FIIG
- Specifications
- T103-F
- Drive Shaft Type [AJAB]
- Splined, Involute External
- Connection Design [AXFC]
- Threaded
- Connection Government Spec/Std [AZFE]
- And 10050-4; And 10050-8; And 10050-8
- Connection Quantity [ASMM]
- 1 And 1 And 1
- Constant Displacement Per Revolution [AXFQ]
- 0.378 Cubic Inches
- Connection Type [AWLS]
- Drain
- Connection Type [AWLS]
- Inlet
- Connection Type [AWLS]
- Outlet
- Fsc Application Data [ZZZV]
- Aircraft Hydraulic System F84
- Housing Material [AJLF]
- Aluminum Alloy
- Housing Surface Treatment [AZFH]
- Anodized
- Displacement Type [AXFP]
- Constant
- Maximum Working Pressure Rating At Specified Temp Range [AXFB]
- 1500 At Minus 65 Deg F To Plus 160 Deg F
- Mounting Bolt Hole Spacing [AZFG]
- 3.536 In. By 3.536 In. C To C
- Mounting Government Standard [AXFN]
- And10261
- Mounting Hole Diameter [ABTB]
- 0.343 Inches Nominal
- Mounting Hole Quantity [ABTJ]
- 4
- Mounting Type [AAXX]
- Flange
- Operating Speed At Rated Capacity In Rpm [AEQC]
- 3750.0
- Pitch Diameter [AGJS]
- 0.600 Inches Nominal
- Sae Key Size Accommodated [AXFL]
- And10261
- Screw Thread Series Designator [AJYP]
- Unf And Unf And Unf
- Shaft Protrusion Length [ARQA]
- 0.750 Inches Nominal
- Shaft Rotation Direction [AKCT]
- Clockwise
- Special Features [FEAT]
- 1 Spline Tooth Milled Off
- Torque Load Rating [AAPL]
- 60.2 Inch-Pounds
- Spline Length [AXFH]
- 0.812 Inches Nominal
- Spline Major Diameter [AAUJ]
- 0.636 Inches Nominal
- Spline Minor Diameter [AAUH]
- 0.536 Inches Nominal
- Spline Pitch [ASAP]
- 20/40
- Spline Pressure Angle In Deg [AXFG]
- 30.0
- Spline Quantity [ABSA]
- 12
- Thread Direction [AAJF]
- Right-Hand And Right-Hand And Right-Hand
- Thread Location [APJC]
- Internal And Internal And Internal
- Thread Size [ABUJ]
- 0.438-20 And 0.750-16 And 0.750-16
Similar Supply Items to 1650-00-529-0623
Freight Information 1650-00-529-0623
1650-00-529-0623 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 1650-00-529-0623 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1650-00-529-0623 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 1650-00-529-0623 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-00-529-0623 is not classified as a special type of cargo when transported by water. 1650-00-529-0623 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
