1650-00-413-0270
Linear Actuating Cylinder Assembly
1650004130270 004130270 123H10071-501
A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies. View more Linear Actuating Cylinder Assembly
May 2023
17
Marketplace 1650-00-413-0270
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-413-0270 5+ Documents (More...)
United States (US) 4. 1650-00-413-0270 Marketplace Restrictions Approved Sources Datasheet Management
CYLINDER ASSEMBLY,ACTUATING,LINEAR 9 EA NS Request Quotation Updated Every Day 1650-00-413-0270
Restrictions 1650-00-413-0270
IUID Required
1650-00-413-0270 is a Linear Actuating Cylinder Assembly that is an aviation critical safety item or flight safety critical aircraft part. The DCMO has forced the Demilization requirements for this item as the ICP has not collaborated. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-00-413-0270
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-413-0270
- US Navy (N2R4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
- Israel (YD01)
- Effective Date:
- 1 Mar 2017
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1996
Approved Sources 1650-00-413-0270
- Part Number
- Manufacturer
- Status
- 123H10071-501
- Manufacturer
- 1SR57 - Triumph Actuation Systems Llc (Active)
- Primary Buy
- Primary Buy
- 123H10071-501
- 26512 - Northrop Grumman Systems Corporation (Active)
- Obsolete Drawing
- Obsolete Drawing
- 123H10071-501
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 1650-00-413-0270
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Body Material [AAFZ]
- Steel
- Bore Diameter [ABXV]
- 2.620 Inches Nominal
- Design Characteristics [CKSD]
- Single Acting Single Cylinder
- Fsc Application Data [ZZZV]
- Hydraulic Systems,Acft
- Port Location And Quantity [CLMS]
- 1 Cylinder Head End And 1 Piston Rod End
- Port Style [CLMT]
- Gasket Seal All Ports
- Port Thread Class [CLNB]
- 3B All Ports
- Port Thread Diameter [CLMX]
- 0.625 Inches Nominal All Ports
- Port Thread Quantity Per Inch [CLMY]
- 18 All Ports
- Port Thread Series Designator [CLMW]
- Unf All Ports
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Nominal
- Seat Angle In Deg [AJFY]
- 60.0 All Ports
Management Data 1650-00-413-0270
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Jan 2021
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 28159.00
- NET PRICE 28159.00
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- BE
- Special Electronic Aircraft (E2/C2)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-00-413-0270
Freight Information 1650-00-413-0270
1650-00-413-0270 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 1650-00-413-0270 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1650-00-413-0270 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 1650-00-413-0270 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-00-413-0270 is not classified as a special type of cargo when transported by water. 1650-00-413-0270 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-00-413-0270
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Validated Correction
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 20.0" H x 6.0" W x 6.0" L
- --
- --
- --
- Any Suitable Process
- 20.0" H x 6.0" W x 6.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- MIL-PRF-26514, Type I, Class 2, Grade C, Flexible Polyurethane Foam, Heavy Load Range
- 1 inch thick
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
