1650-00-244-4936
Linear Actuating Cylinder Assembly
1650002444936 002444936 216-22041-2
A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies. View more Linear Actuating Cylinder Assembly
May 2023
6
Marketplace 1650-00-244-4936
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-244-4936 5+ Documents (More...)
United States (US) 4. 1650-00-244-4936 Marketplace Restrictions Approved Sources Datasheet Management
Request a Quotation from participating marketplace vendors Request Updated Every Day 1650-00-244-4936
Restrictions 1650-00-244-4936
1650-00-244-4936 is a Linear Actuating Cylinder Assembly This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-00-244-4936
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-244-4936
- US Navy (N2R4)
- Effective Date:
- 1 Aug 1996
- Supplementary Receivers:
- GG
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
Approved Sources 1650-00-244-4936
- Part Number
- Manufacturer
- Status
- 216-22041-2
- Manufacturer
- 80378 - Triumph Aerostructures, Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 1650-00-244-4936
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Compressed Length [AMQZ]
- 8.180 Inches Nominal
- Design Characteristics [CKSD]
- Single Acting Single Cylinder
- Extended Length [ATEM]
- 11.410 Inches Nominal
- Mounting Provision [ABDR]
- Unthreaded Mounting Holes
- Mounting Type And Location [CLML]
- Lug Cylinder Head End
- Integral Valve Operation Method [CKRM]
- Hydraulic
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Nominal
- Temp Rating [ABJH]
- -65.0 Deg Fahrenheit
- Temp Rating [ABJH]
- 275.0 Deg Fahrenheit
Management Data 1650-00-244-4936
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 1335.00
- NET PRICE 1335.00
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- TA
- Attack Aircraft (A7E)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-00-244-4936
Freight Information 1650-00-244-4936
1650-00-244-4936 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 119260. A Sub NMFC of X. It has a NMFC Description of CYLINDERS:HYDRAULIC/PNEUMATIC. 1650-00-244-4936 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 60780 which rates the freight between FCL and LCL. 1650-00-244-4936 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 1650-00-244-4936 is not classified as a special type of cargo when transported by water. 1650-00-244-4936 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-00-244-4936
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Validated Correction
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 12.5" H x 8.3" W x 4.0" L
- --
- --
- --
- Any Suitable Process
- 12.5" H x 8.3" W x 4.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-23827, Grease, Aircraft and Instrument, Gear and Actuator Screw
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- --
- --
- PPP-B-1672, Type II, Folding Convoluted Cushioning in Reusable Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
