1650-00-226-5789
Linear Actuating Cylinder Assembly
1650002265789 002265789 6-43150-2
A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies. View more Linear Actuating Cylinder Assembly
May 2023
24
Marketplace 1650-00-226-5789
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-226-5789 4+ Documents (More...)
Photo 1/3 1650-00-226-5789 Photo 2/3 1650-00-226-5789 Photo 3/3 - - - 1.
United States (US) 4. 1650-00-226-5789 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 1650-00-226-5789
IUID Required
1650-00-226-5789 is a Linear Actuating Cylinder Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1650-00-226-5789
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-226-5789
- US Air Force (FXX4)
- Effective Date:
- 1 Apr 1991
- US Navy (NAXS)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 1650-00-226-5789
- Part Number
- Manufacturer
- Status
- 6-43150-2
- Manufacturer
- 76823 - Northrop Grumman Systems Corporation (Active)
- Original Design
- Original Design
- 6-43150-2
- 0JRC1 - Northrop Grumman Technical Services, (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6-43150-2
- 79U29 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 1650-00-226-5789
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Bore Diameter [ABXV]
- 1.688 Inches Nominal
- Compressed Length [AMQZ]
- 8.620 Inches Nominal
- Design Characteristics [CKSD]
- Single Acting Single Cylinder
- Extended Length [ATEM]
- 13.300 Inches Nominal
- Integral Valve Operation Method [CKRM]
- Hydraulic
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Maximum
- Overall Height [ABKW]
- 2.875 Inches Nominal
- Overall Width [ABMK]
- 2.265 Inches Nominal
Management Data 1650-00-226-5789
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2020
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- L
- R
- Refer To Net Price 8833.55
- NET PRICE 8833.55
- R
- Department of the Navy (DN)
- N
- R
- Refer To Net Price 5403.96
- NET PRICE 5403.96
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- VF
- Fighter Aircraft (F5 E/F)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-00-226-5789
Freight Information 1650-00-226-5789
1650-00-226-5789 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 119260. A Sub NMFC of X. It has a NMFC Description of CYLINDERS:HYDRAULIC/PNEUMATIC. 1650-00-226-5789 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 60780 which rates the freight between FCL and LCL. 1650-00-226-5789 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-00-226-5789 is not classified as a special type of cargo when transported by water. 1650-00-226-5789 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-00-226-5789
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 8.6" H x 2.3" W x 2.9" L
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 4.3" H x 4.3" W x 12.5" L
- --
- --
- --
- Any Suitable Process
- 4.3" H x 4.3" W x 12.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
