1650-00-076-6278
Linear Actuating Cylinder Assembly
1650000766278 000766278 123H10071-401 123H10071-5 123H10071-7 123H10071-1
A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies. View more Linear Actuating Cylinder Assembly
May 2023
13
Marketplace 1650-00-076-6278
Request a Quotation from participating marketplace vendors
Related Documents 1650-00-076-6278 3+ Documents (More...)
Photo 1/4 1650-00-076-6278 Photo 2/4 1650-00-076-6278 Photo 3/4 NSN 1650-00-076-6278 (Identification
CYLINDER ASSEMBLY,ACTUATING,LINEAR 1 EA NS Request Quotation Updated Every Day 1650-00-076-6278
Restrictions 1650-00-076-6278
Import and Export 1650-00-076-6278
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1650-00-076-6278
- US Navy (N2R4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
Approved Sources 1650-00-076-6278
- Part Number
- Manufacturer
- Status
- 123H10071-1
- Manufacturer
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
- 123H10071-5
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123H10071-7
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123H10071-1
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123H10071-401
- 26512 - Northrop Grumman Systems Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 123H10071-401
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
- 123H10071-5
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
- 123H10071-7
- 79RG9 - Northrop Grumman Systems Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 1650-00-076-6278
- Characteristic
- Specifications
- FIIG
- Specifications
- A34200
- Body Material [AAFZ]
- Steel
- Bore Diameter [ABXV]
- 2.620 Inches Nominal
- Compressed Length [AMQZ]
- 15.938 Inches Nominal
- Design Characteristics [CKSD]
- Double Acting Single Cylinder
- Extended Length [ATEM]
- 20.875 Inches Nominal
- Fsc Application Data [ZZZV]
- Hydraulic System,Aircraft
- Port Style [CLMT]
- Gasket Seal
- Port Thread Class [CLNB]
- 3B
- Port Thread Diameter [CLMX]
- 0.562 Inches Nominal
- Port Thread Quantity Per Inch [CLMY]
- 18
- Port Thread Series Designator [CLMW]
- Unf
- Pressure Rating [BGST]
- 3000.0 Pounds Per Square Inch Nominal
- Seat Angle In Deg [AJFY]
- 60.0
- Overall Height [ABKW]
- 5.062 Inches Nominal
- Overall Width [ABMK]
- 5.062 Inches Nominal
- Special Features [FEAT]
- Designed For Lefthand Application
Management Data 1650-00-076-6278
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Jan 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 28159.00
- NET PRICE 28159.00
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- BE
- Special Electronic Aircraft (E2/C2)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1650-00-076-6278
Freight Information 1650-00-076-6278
1650-00-076-6278 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 133300. A Sub NMFC of Z. It has a NMFC Description of MACHINERY/MACHINES NOI. 1650-00-076-6278 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1650-00-076-6278 is rated as a variable freight class when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 63220 which rates the freight between FCL and LCL. 1650-00-076-6278 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1650-00-076-6278 is not classified as a special type of cargo when transported by water. 1650-00-076-6278 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1650-00-076-6278
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Validated Correction
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 19.0" H x 7.0" W x 7.0" L
- --
- --
- --
- Any Suitable Process
- 19.0" H x 7.0" W x 7.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- MIL-PRF-26514, Type I, Class 2, Grade C, Flexible Polyurethane Foam, Heavy Load Range
- 1 inch thick
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
