1630-01-143-5706
Brake Control Servovalve Assembly
1630011435706 011435706 MC12362-5 10153835
INC: 77777
November 2023
18
Product Information 1630-01-143-5706
Dual Brake Valve
Used on Boeing F/A-18E/F “Super Hornet” Strike Fighter
Eaton's dual brake valves provide independent and proportional brake control to the right and left main landing gear brakes under normal and emergency conditions. The dual brake valves are a hydraulic servo design that provides a hydraulic pressure output proportional to the pilot's mechanical input force. he brake valve provides normal brake pressure, emergency brake pressure and parking brake pressure using 3000 psi (20,600 kPa) system pressure.
Marketplace 1630-01-143-5706
Request a Quotation from participating marketplace vendors
Related Documents 1630-01-143-5706 5+ Documents (More...)
NATO Update Count 18 NATO Data Quality 1630-01-143-5706 Photo 1/1 1.
United States (US) 4. 1630-01-143-5706 Marketplace Restrictions Approved Sources Datasheet Management
Brake Control Servovalve Assembly 011435706 Upgrade your Account Upgrade 1630-01-143-5706Brake
Control Servovalve Assembly1630011435706 011435706 MC12362-5 NumberManufacturerStatusMC12362-5 76301
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 10153835
Related Documents 5935-00-949-8538 2+ Documents https//www.nsnlookup.com /fsg-16/fsc-1630/us 1630-01-143-5706
Restrictions 1630-01-143-5706
IUID Required
1630-01-143-5706 is a Brake Control Servovalve Assembly This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 1630-01-143-5706
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1630-01-143-5706
- US Navy (N2R4)
- Effective Date:
- 1 Apr 1991
- Supplementary Receivers:
- GG
- Finland (WF01)
- Effective Date:
- 1 Jun 2009
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 1630-01-143-5706
- Part Number
- Manufacturer
- Status
- MC12362-5
- Manufacturer
- 76301 - The Boeing Company (Active)
- Primary Buy
- Primary Buy
- MC12362-5
- 99643 - Eaton Aerospace Llc (Active)
- Secondary Buy
- Secondary Buy
- MC12362-5
- 76050 - Eaton Aerospace Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 10153835
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Datasheet 1630-01-143-5706
- Characteristic
- Specifications
- FIIG
- Specifications
- A23900
- End Item Identification [AGAV]
- Aircraft Model F-18
- General Characteristics Item Description [TEXT]
- Body-Aluminum,Type 7075-T73; Anodized; Designed For Hydraulic Fluid Per Mil-H-83282; Ambient Temperature Rating,Minus 65.0 Deg F To Plus 275.0 Deg F; 3000.0 Psig Pressure Port Operating Pressure; 85.0 Psig Return Port Operating Pressure
Management Data 1630-01-143-5706
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Oct 2020
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- Nov 2019
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- L
- R
- Refer To Net Price 23644.00
- NET PRICE 23644.00
- R
Navy
- Cognizance:
- 7R
- Bypass
- Special Material ID:
- GF
- Fighter Support Aircraft (F/A-18)
- Issue, Repair, Requisition Restriction Code:
- AR
- Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
Similar Supply Items to 1630-01-143-5706
Freight Information 1630-01-143-5706
1630-01-143-5706 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 051080. A Sub NMFC of Z. It has a NMFC Description of FAUCETS,BIBCOCKS,GATES VALVES. 1630-01-143-5706 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. 1630-01-143-5706 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 29300 which rates the freight between FCL and LCL. 1630-01-143-5706 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 671 for ocean manifesting and military sealift. 1630-01-143-5706 is not classified as a special type of cargo when transported by water. 1630-01-143-5706 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1630-01-143-5706
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Validated Correction
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 13.0" H x 11.0" W x 6.0" L
- --
- --
- --
- Any Suitable Process
- 13.0" H x 11.0" W x 6.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-83282, Hydraulic Fluid, Synthetic, Fire retardant
- MIL-PRF-121, Greaseproof, Waterproof Barrier
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- 1 inch thick
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- No special marking
- MIL-PRF-121, Greaseproof, Waterproof Barrier
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
