1560-00-065-8889
Bleed Air Duct Assembly
1560000658889 000658889 20421-800 32-15404-305
An item specifically designed to transfer warmed high pressure gases (bleed air) from the engine to various systems of an aircraft. View more Bleed Air Duct Assembly
May 2023
29
Marketplace 1560-00-065-8889
Request a Quotation from participating marketplace vendors
Related Documents 1560-00-065-8889 1+ Documents (More...)
United States (US) 4. 1560-00-065-8889 Marketplace Restrictions Approved Sources Datasheet Management
DUCT ASSEMBLY,BLEED AIR 17 EA NS Request Quotation Subscribe to View Vendor Details... 20421-800
Restrictions 1560-00-065-8889
IUID Required
1560-00-065-8889 is a Bleed Air Duct Assembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 1560-00-065-8889
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1560-00-065-8889
- US Air Force (FUU4)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 May 2006
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 1560-00-065-8889
- Part Number
- Manufacturer
- Status
- 20421-800
- Manufacturer
- 66195 - Solar Turbines Incorporated (Active)
- Primary Buy
- Primary Buy
- 32-15404-305
- 34087 - Kitco Llc (Active)
- Secondary Buy
- Secondary Buy
- 32-15404-305
- 56540 - Associated Aircraft Manufacturing & (Active)
- Secondary Buy
- Secondary Buy
- 32-15404-305
- 8X044 - Derco Aerospace, Inc. (Active)
- Secondary Buy
- Secondary Buy
- 32-15404-305
- 76301 - The Boeing Company (Active)
- Secondary Buy
- Secondary Buy
- 20421-800
- 01234 - Steris Barrier Products Solutions, (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 20421-800
- 55820 - Rtx Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 1560-00-065-8889
- Characteristic
- Specifications
- FIIG
- Specifications
- A11800
- Aircraft Mission Design Series [CZEK]
- F-4
- Part Name Assigned By Controlling Agency [CXCY]
- Chamber Assy, Lead Air
Similar Supply Items to 1560-00-065-8889
Freight Information 1560-00-065-8889
1560-00-065-8889 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 1560-00-065-8889 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 1560-00-065-8889 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 1560-00-065-8889 is not classified as a special type of cargo when transported by water. 1560-00-065-8889 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1560-00-065-8889
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 32.0" H x 4.0" W x 4.0" L
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 34.0" H x 14.0" W x 10.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 34.0" H x 14.0" W x 10.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
- Reusable container
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
