1377-01-232-6401

Detonating Cord Assembly

1377012326401 012326401 816739-96083 1377-SF16

An item consisting of a definite length of detonating cord, having ends which are terminated with caps containing a quantity of explosive. The ends also incorporate a means to permit connection to another detonating cord assembly or item. View more Detonating Cord Assembly

Managed by United States

NSN Created on 18 May 1986

Data Last Changed
May 2023

NATO Update Count
54

NATO Data Quality

1377-01-232-6401 CORD ASSEMBLY,DETONATING 1377012326401 012326401 1/1 — 1377-01-232-6401 Photo 1/1

Marketplace 1377-01-232-6401

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

1377-01-232-6401 RQST NE

Restrictions 1377-01-232-6401

1377-01-232-6401 is a Detonating Cord Assembly that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.

Import and Export 1377-01-232-6401

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1377-01-232-6401

US Air Force (FUU4)
Effective Date:: 1 Jul 1994
Former MOE Rule:: FUU5; AMC 1 AMSC C AMSC F DSOR FH

MOE Rule:: WN01
Effective Date:: 1 Nov 1998

Approved Sources 1377-01-232-6401

Part Number
Manufacturer
Status
816739-96083: 06331 - Pacific Scientific Energetic (Active); Primary Buy; RNCC 3 RNVC 2 DAC 2
1377-SF16: 99999 - Department Of Defense Ammunition (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 1377-01-232-6401

Characteristic
Specifications
FIIG: T165-C
Dod Ammunition Code [DDAC]: 1377-Sf16
Dot Hazard Class/Division [HAZD]: 1.4
Dot Identification Number [DENN]: Un0257
Dot Proper Shipping Name [SHPN]: Fuzes, Detonating
Dot Registration Code [DTRC]: Ex1988070367
Dot Warning Label Code [WLBL]: 1.4B
End Item Identification [AGAV]: B-1B Acft
Criticality Code Justification [CRTL]: Exwt
Cross-Sectional Shape [ANLR]: Circular
Diameter [ABMZ]: 0.191 Inches Nominal
Environmental Protection [ADZC]: Waterproof
Exterior Covering Material [AFPJ]: Steel
Filler Material [ANHA]: Hexanitrostilbene, Hns Type 1, Grade A
Hazardous Material Classification Code [HMCC]: 1.4 Department Of Defense Hazard Class Division
Net Explosive Weight [EXWT]: 0.0012 Storage Pounds And 0.0012 Transportation Pounds
Length [ABRY]: 27.100 Inches Nominal
Special Features [FEAT]: Smdc Assy
Termination Type [AKRZ]: Any Acceptable

Management Data 1377-01-232-6401

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Apr 2020: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): L; N; Disposal

Air Force

Fund:

IN: Insurance item

Budget:

S: 57X3010 - Aircraft Replenishment Spares

Aggregation Code:

ES: CARTRIDGE AND PROPELLANT ACTUATED DEVICES

Price Validation Code:

E: The current standard price is an estimated price.
Estimated Price challenges are allowed but follow procedures in para 60.b. (3) of section L of this manual.
This code will be changed to a P code upon notification of a contract price or this code will be changed to an updated code upon determination of a valid price.

NATO Stock Numbers Related to 1377-01-232-6401

1377-14-509-6472 1375-16-004-6888 1377-00-263-3860 1377-14-509-6466 1377-00-060-5758 1375-16-004-6887 1377-99-866-9180 1375-12-389-4215 1377-01-398-4194 1377-01-400-3932 1337-01-496-4069 1375-01-647-3834 1377-01-446-7657 1377-01-462-2328 1377-01-461-8080 1377-01-198-7482 1377-01-125-9504 1337-01-169-7390

Freight Information 1377-01-232-6401

1377-01-232-6401 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 064300. A Sub NMFC of B. It has a NMFC Description of EXPLOSIVES:AMMO OR CARTRIDGES SUB2. 1377-01-232-6401 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 1377-01-232-6401 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 05980 which rates the freight between FCL and LCL. 1377-01-232-6401 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 400 for ocean manifesting and military sealift. 1377-01-232-6401 is classified as Explosive Class C, UN Class 1.4, when transported by water. 1377-01-232-6401 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 1377-01-232-6401

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 28.0" H x 4.0" W x 1.0" L; --; --; --; --

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 6.4" H x 6.4" W x 36.8" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
