1340-01-443-5477
83 Millimeter Rocket And Launcher
1340014435477 014435477 51950 52105 1340-HA08
A high emplosive, dual purpose, (HEDP) shoulder mounted, disposal assault weapon (SMAW-D). The light weight portable, single shot item, is designed to have an effective range of 15-150 meters. Excludes LAUNCHER AND CARTRIDGE (as modified) and LAUNCHER, ROCKET. View more 83 Millimeter Rocket And Launcher
November 2023
16
Product Information 1340-01-443-5477
M141 BUNKER DEFEAT MUNITION (BDM)
BDM is the first lightweight shoulder-fired weapon system with true Multipurpose effectiveness, and uses the same High Explosive Dual Purpose (HEDP) rocket as in the USMC SMAW. The HEDP rocket is packaged in a rugged, compact telescoping, disposable launcher that has all gunner controls needed to aim and fire the weapon. The BDM is highly effective against double reinforced concrete, triple brick, solid adobe, earthen fortifications, caves and technical vehicles.
System weight and caliber 7.2 kg, 83 mm
Carry/extended length 812 mm/1 372 mm
Warhead type (explosive) Anti-Structure/Anti-Fortification (Aluminized HE)
Fuze M420, dual safety, self-discriminating at impact (delay or impact)
Muzzle velocity 220 m/s
Minimum, effective and
maximum range 15, 250 and 2 000 m
Service temperature -45°C to +70°C
Marketplace 1340-01-443-5477
Request a Quotation from participating marketplace vendors
Related Documents 1340-01-443-5477 5+ Documents (More...)
United States (US) 4. 1340-01-443-5477 Marketplace Restrictions Approved Sources Datasheet Management
(Active) Primary Buy RNCC 3 RNVC 2 DAC 1 51950 12116 - Nammo Defense Systems Inc.
Rocket And Launcher1340014435477 014435477 51950 Gasket 5330996705259 996705259,51950 enable JavaScript
144626-51950 A nonmetallic circular item with an aperature, having a solid round cross-section. https
0099 Wire Wound Fixed Resistor 1340-21-913-4775 https//www.nsnlookup.com /fsg-13/fsc-1340/us 1340-01-443-5477
83 Millimeter Rocket And Launcher 014435477 www.nsnlookup.com /fsg-13 Rockets, Rocket Ammunition
www.nsnlookup.com /fsg-53/fsc-5305/us 5305-00-575-7118 Special Screw 5305005757118 005757118,51950 51950
Special Screw 5305005757118 005757118,51950 0421Check Valve4820190050421 190050421 148620-51950 575-
/fsg-13/fsc-1340/de
83 Millimeter Rocket And Launcher 014435477 Ammunition and Rocket Components (FSC 1340) Wound Fixed
Restrictions 1340-01-443-5477
IUID Required
1340-01-443-5477 is a 83 Millimeter Rocket And Launcher that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1340-01-443-5477
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1340-01-443-5477
- US Army (A901)
- Effective Date:
- 1 Apr 1997
- MOE Rule:
- WN01
- Effective Date:
- 1 Feb 2006
- Republic of Korea (ZH01)
- Effective Date:
- 1 Jun 2015
Approved Sources 1340-01-443-5477
- Part Number
- Manufacturer
- Status
- 52105
- Manufacturer
- 12116 - Nammo Defense Systems Inc. (Active)
- Primary Buy
- Primary Buy
- 51950
- 12116 - Nammo Defense Systems Inc. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 1340-HA08
- 99999 - Department Of Defense Ammunition (Active)
- NATO Reference
- NATO Reference
Datasheet 1340-01-443-5477
- Characteristic
- Specifications
- FIIG
- Specifications
- T357-A
- Dod Ammunition Code [DDAC]
- 1340-Ha08
- Head Load Type [ATNB]
- Explosive
- Dot Registration Code [DTRC]
- Ex1998040127
- Model Number [AMWN]
- M141
- Hazardous Material Classification Code [HMCC]
- 1.2.1 Department Of Defense Hazard Class Division
- Net Explosive Weight [EXWT]
- 3.35 Storage Pounds And 3.35 Transportation Pounds
- Special Features [FEAT]
- Bunker Defeat Munition (Bdm).
Management Data 1340-01-443-5477
Army
- Materiel Category and Inventory Manager:
- D
- Single Manager Ammunition
- Appropriation and Budget Activity:
- K
- Ammunition
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- XX
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Similar Supply Items to 1340-01-443-5477
Freight Information 1340-01-443-5477
1340-01-443-5477 has freight characteristics.. 1340-01-443-5477 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 1340-01-443-5477
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Ammunition (Class V; Igloos and Magazines)
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 39.9" H x 9.2" W x 9.2" L
- --
- --
- --
- Special Requirements
- 39.9" H x 9.2" W x 9.2" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
