1340-25-152-8309

M72 ANTI-STRUCTURE MUNITION REDUCED CALIBER (ASM RC)

The M72 Anti-Structure Munition Reduced Caliber (ASM RC) combines decades of innovation and Nammo expertise to deliver a world-leading close combat weapon. The system is disposable, easy to operate, extremely lightweight and powerful. The M72 ASM RC variant is suitable for defeating brick, adobe, earthen fortifications and technical vehicles. The carbon fiber warhead gives low collateral damage. The dual safe fuze and on-axis trigger equip the warfighter with an improved weapon system that is both safe and effective.

System weight and caliber 3.7 kg, 42 mm
Carry/extended length 780 mm/980 mm
Warhead type (explosive) Anti-Structure  (415 g DPX-6, Aluminized HE)
Fuze Electronic piezo fuze, dual-mode  (short and long delay), dual safe  with graze function
Muzzle velocity 170 m/s (21°C)
Dispersion < 1.5 mils at 150 m
Minimum, effective and
maximum range 14, 350 and 1 000 m
Service temperature -40°C to +60°C
