1336-01-437-5664
Impulse Cartridge
1336014375664 014375664 VE325-5003-0002 9391959-1 1336-VA34
An item consisting of a quantity of propellant and a means of activation inclosed in a container. It may contain an integral cutting punch. It is designed to be inserted into or attached to one or more devices to provide the energy required to operate a device not requiring a time delay in their operating sequence. It is used in devices, such as initiators, thrusters, cutters, and the like. For cartridges with a time delay see CARTRIDGE, DELAY. View more Impulse Cartridge
May 2023
102
Marketplace 1336-01-437-5664
Request a Quotation from participating marketplace vendors
Related Documents 1336-01-437-5664 4+ Documents (More...)
Photo 1/2 1336-01-437-5664 Photo 2/2 - - 1.
United States (US) 4. 1336-01-437-5664 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 1336-01-437-5664
1336-01-437-5664 is a Impulse Cartridge that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1336-01-437-5664
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1336-01-437-5664
- US Air Force (FUU5)
- Effective Date:
- 1 Oct 1996
- MOE Rule:
- WN01
- Effective Date:
- 1 Feb 2006
Approved Sources 1336-01-437-5664
- Part Number
- Manufacturer
- Status
- VE325-5003-0002
- Manufacturer
- 51215 - Boeing Company, The (Active)
- Source Control
- Source Control
- 9391959-1
- 7X644 - Midwest Testing Laboratories, Inc (Active)
- Primary Buy
- Primary Buy
- 9391959-1
- 73197 - Hi-Shear Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 1336-VA34
- 99999 - Department Of Defense Ammunition (Active)
- NATO Reference
- NATO Reference
Datasheet 1336-01-437-5664
- Characteristic
- Specifications
- FIIG
- Specifications
- T190-A
- Dod Ammunition Code [DDAC]
- 1336-Va34
- Dot Hazard Class/Division [HAZD]
- 1.4
- Dot Identification Number [DENN]
- Un0276
- Dot Proper Shipping Name [SHPN]
- Cartridges, Power Device
- Dot Warning Label Code [WLBL]
- 1.4C
- Dot Registration Code [DTRC]
- Ex2001090116
- End Item Identification [AGAV]
- Agm-130 Missile System
- Body Diameter [ABPM]
- 0.750 Inches Nominal
- Case Mounting Thread [ATGC]
- Included
- Case Threaded Electrical Connection [ATGE]
- Not Included
- Color Coded Feature [ATGK]
- Not Included
- Criticality Code Justification [CRTL]
- Feat
- Detonation Initiation Method [AHVN]
- Electric
- Hazardous Material Classification Code [HMCC]
- 1.4 Department Of Defense Hazard Class Division
- Mounting Thread Series [ATGD]
- Unf
- Net Explosive Weight [EXWT]
- 0.0058 Storage Pounds And 0.0058 Transportation Pounds
- Integral Cutting Punch [ATGB]
- Not Included
- Rim [ATGL]
- Not Included
- Overall Length [ABHP]
- 1.395 Inches Nominal
- Part Name Assigned By Controlling Agency [CXCY]
- Power Cartridge
- Special Features [FEAT]
- Contains Explosives
- Thread Size [ABUJ]
- 0.625-18
- Thread Class [AAJD]
- 2A
Management Data 1336-01-437-5664
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Apr 2018
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Air Force (DF)
- I
- V
- Discontinued Without Replacement
- V
Similar Supply Items to 1336-01-437-5664
Freight Information 1336-01-437-5664
1336-01-437-5664 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 064300. A Sub NMFC of B. It has a NMFC Description of EXPLOSIVES:AMMO OR CARTRIDGES SUB2. 1336-01-437-5664 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 05980 which rates the freight between FCL and LCL. 1336-01-437-5664 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 412 for ocean manifesting and military sealift. 1336-01-437-5664 is classified as Explosive Class C, UN Class 1.4, when transported by water. 1336-01-437-5664 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
