1325-00-710-6768

General Purpose Bomb

1325007106768 007106768 1380901-4 LD165796 1325-E482

An item designed to be dropped from an aircraft to destroy or reduce the utility of a target by explosive effect. The bomb is designed to be used against both material targets and personnel. When empty or inert loaded the bomb may be used for training purposes. View more Utility Bomb

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
May 2023

NATO Update Count
24

NATO Data Quality

1325-00-710-6768 BOMB,GENERAL PURPOSE 1325007106768 007106768 1/3 — 1325-00-710-6768 Photo 1/3

1325-00-710-6768 BOMB,GENERAL PURPOSE 1325007106768 007106768 2/3 — 1325-00-710-6768 Photo 2/3

1325-00-710-6768 BOMB,GENERAL PURPOSE 1325007106768 007106768 3/3 — 1325-00-710-6768 Photo 3/3

Marketplace 1325-00-710-6768

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

1325-00-710-6768 RQST NE

Restrictions 1325-00-710-6768

1325-00-710-6768 is a General Purpose Bomb that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1325-00-710-6768

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1325-00-710-6768

US Army (A901)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC J DSOR 00

US Navy (NGFF)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC 7 DSOR 00

MOE Rule:: WN01
Effective Date:: 1 Feb 2006

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

Approved Sources 1325-00-710-6768

Part Number
Manufacturer
Status
1380901-4: 30003 - Naval Air Systems Command Managed (Active); Incomplete Reference; RNCC 3 RNVC 1 DAC 1
LD165796: 30003 - Naval Air Systems Command Managed (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 1
1325-E482: 99999 - Department Of Defense Ammunition (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 1325-00-710-6768

Characteristic
Specifications
FIIG: T147-C
Dot Hazard Class/Division [HAZD]: 1.1
Dot Identification Number [DENN]: Un0034
Dot Proper Shipping Name [SHPN]: Bombs
Dod Ammunition Code [DDAC]: 1325-E482
Dot Registration Code [DTRC]: Ex1988060669
Base Type [ACVM]: Plug
Criticality Code Justification [CRTL]: Exwt
Filler Material Weight [AQRP]: 192.00 Pounds
Filler Material [ANHA]: H-6
Fin Assembly Installation Feature [AQRT]: Not Installed
Gross Weight [GRWT]: 3228.0 Shipping Container Pounds And 3228.0 Pallet Fleet, Us Navy Pounds
Harness Model Number [AQRS]: M72 Or M73
Harness [AQRR]: Included
Hazardous Material Classification Code [HMCC]: 1.1 Department Of Defense Hazard Class Division
Model Number [AMWN]: Mk 82 Mod 1
Net Explosive Weight [EXWT]: 192.00000 Storage Pounds And 192.00000 Transportation Pounds
Nominal Weight [AQNM]: 500.0 Pounds
Item Content [AQPF]: Explosive Filled
Plumbing [AQRQ]: Included
Quantity Per Shipping Container [QTSC]: 6
Reference Number Differentiating Characteristics [ZZZY]: Differentiated By Explosive Filler And Harness
Shipping Container Quantity Per Pallet [SCQP]: 1 Navy Pallet Fleet
Package Nominal Overall Height [PKNH]: 27.00 Inches Navy Pallet Fleet
Package Nominal Overall Height [PKNH]: 27.00 Inches Shipping Container
Package Nominal Overall Length [PKNL]: 67.25 Inches Navy Pallet Fleet
Package Nominal Overall Length [PKNL]: 67.25 Inches Shipping Container
Package Nominal Overall Width [PKNW]: 33.75 Inches Navy Pallet Fleet
Package Nominal Overall Width [PKNW]: 33.75 Inches Shipping Container
Package Reference Number [CZKA]: Wr54-31 Us Navy
Special Features [FEAT]: Net Explosive Weight:Shipboard 192.0000 Lbs,87.0897 Kilograms
Suspension Lug [AQRK]: Not Included

Management Data 1325-00-710-6768

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Aug 1992: Department of the Navy (DN); EA; Subscribe; 6
May 1991: Department of the Army (DA); EA; Subscribe; 6

Army

Materiel Category and Inventory Manager:

D: Single Manager Ammunition

Appropriation and Budget Activity:

K: Ammunition

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

XF: Special Ammunition
Bombs, General Purpose

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

2E: Conventional air ammunition
Naval Ordnance Center, IMSD Mechanicsburg, PA

Issue, Repair, Requisition Restriction Code:

BV: Controlled ammunition item. Submit/refer requisitions to NOC IMSD. Centralized control for issue of controlled ammunition items

NATO Stock Numbers Related to 1325-00-710-6768

1325-14-453-9248 1325-14-417-8966 1325-14-421-4200 1325-00-540-7629 1325-14-453-9251 1325-14-308-2141 1325-00-465-7285 1325-00-691-4653 1325-14-528-3148 1325-00-028-5266 1325-00-028-5335 1325-00-028-6025 1325-01-074-5696 1325-14-453-3248 1325-01-537-1503 1325-01-600-7907 1325-01-089-7399 1325-14-453-9451

Freight Information 1325-00-710-6768

1325-00-710-6768 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 064300. A Sub NMFC of A. It has a NMFC Description of EXPLOSIVES:AMMO OR CARTRIDGES SUB1. 1325-00-710-6768 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. 1325-00-710-6768 is rated as class 200 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 05980 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 423 for ocean manifesting and military sealift. 1325-00-710-6768 is classified as Explosive Class A, UN Class 1.1 or 1.2, when transported by water. 1325-00-710-6768 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air. This item is Hazardous and is described as "EXPLOSIVE BOMB CLASS A EXPLOSIVE".

Packaging Data 1325-00-710-6768

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Ammunition (Class V; Igloos and Magazines)

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 6; 61.8" H x 33.8" W x 27.0" L; --; --; --; Special Requirements

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Special Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; --

Intermediate Pack Level

Quantity of Unit Packs
Container: --
