1325-00-710-6765

General Purpose Bomb

1325007106765 007106765 1380911 6214081 1380523 1325-F127

An item designed to be dropped from an aircraft to destroy or reduce the utility of a target by explosive effect. The bomb is designed to be used against both material targets and personnel. When empty or inert loaded the bomb may be used for training purposes. View more Utility Bomb

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
May 2023

NATO Update Count
21

NATO Data Quality

1325-00-710-6765 BOMB,GENERAL PURPOSE 1325007106765 007106765 1/1 — 1325-00-710-6765 Photo 1/1

Marketplace 1325-00-710-6765

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

1325-00-710-6765 RQST NE

Restrictions 1325-00-710-6765

1325-00-710-6765 is a General Purpose Bomb that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.

Import and Export 1325-00-710-6765

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1325-00-710-6765

US Army (A901)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC J DSOR 00

US Air Force (F2BF)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC 7 DSOR 00

US Navy (NGFF)
Effective Date:: 1 Apr 1991; AMC 0 AMSC 0 AMSC 7 DSOR 00

MOE Rule:: WN01
Effective Date:: 1 Feb 2006

Germany (ZG01)
Effective Date:: 1 Mar 1995

Greece (ZU01)
Effective Date:: 1 Mar 2005

Turkey (ZW01)
Effective Date:: 1 Nov 2005

Approved Sources 1325-00-710-6765

Datasheet 1325-00-710-6765

Characteristic
Specifications
FIIG: T147-C
Dot Hazard Class/Division [HAZD]: 1.1
Dot Identification Number [DENN]: Un0034
Dot Proper Shipping Name [SHPN]: Bombs
Dod Ammunition Code [DDAC]: 1325-F127
Dot Registration Code [DTRC]: Ex1988060668
Base Type [ACVM]: Plug
Criticality Code Justification [CRTL]: Exwt
Filler Material Weight [AQRP]: 945.00 Pounds
Filler Material [ANHA]: H-6
Fin Assembly Installation Feature [AQRT]: Not Installed
Gross Weight [GRWT]: 4225.0 Shipping Container Pounds
Harness Model Number [AQRS]: M74 Or T15
Harness [AQRR]: Included
Hazardous Material Classification Code [HMCC]: 1.1 Department Of Defense Hazard Class Division
Model Number [AMWN]: Mk84 Mod 1 And 2
Net Explosive Weight [EXWT]: 945.00000 Storage Pounds And 945.00000 Transportation Pounds
Nominal Weight [AQNM]: 2000.0 Pounds
Item Content [AQPF]: Explosive Filled
Plumbing [AQRQ]: Included
Quantity Per Shipping Container [QTSC]: 2
Package Nominal Overall Height [PKNH]: 23.00 Inches Shipping Container
Package Nominal Overall Height [PKNH]: 24.30 Inches Army Pallet
Package Nominal Overall Length [PKNL]: 104.00 Inches Army Pallet
Package Nominal Overall Length [PKNL]: 99.00 Inches Shipping Container
Package Nominal Overall Width [PKNW]: 38.00 Inches Army Pallet
Package Nominal Overall Width [PKNW]: 38.00 Inches Shipping Container
Package Reference Number [CZKA]: 6214081 Us Navy
Special Features [FEAT]: Mod 1 Has Slotted Hoisting Lug Hole And Mod 2 Has A Threaded Hoisting Lug Hole;Net Explosive Kilograms Weight 428.64490
Suspension Lug [AQRK]: Not Included

Management Data 1325-00-710-6765

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2008: Department of the Air Force (DF); EA; Subscribe; 2
Aug 1992: Department of the Navy (DN); EA; Subscribe; 2
May 1991: Department of the Army (DA); EA; Subscribe; 2

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): F; R; Refer To Afm73; AFM73
Department of the Air Force (DF): F; R; Refer To Afm74; AFM74
Department of the Air Force (DF): F; R; Refer To To 1-1-46; TO 1-1-46

Army

Materiel Category and Inventory Manager:

D: Single Manager Ammunition

Appropriation and Budget Activity:

K: Ammunition

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

XF: Special Ammunition
Bombs, General Purpose

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Air Force

Budget:

H: 57X3080 - Munitions and Associated Equipment

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Navy

Cognizance:

2E: Conventional air ammunition
Naval Ordnance Center, IMSD Mechanicsburg, PA

Issue, Repair, Requisition Restriction Code:

BV: Controlled ammunition item. Submit/refer requisitions to NOC IMSD. Centralized control for issue of controlled ammunition items

NATO Stock Numbers Related to 1325-00-710-6765

1325-14-453-9248 1325-14-417-8966 1325-14-421-4200 1325-00-540-7629 1325-14-453-9251 1325-14-308-2141 1325-00-465-7285 1325-00-691-4653 1325-14-528-3148 1325-00-028-5266 1325-00-028-5335 1325-00-028-6025 1325-01-074-5696 1325-14-453-3248 1325-01-537-1503 1325-01-600-7907 1325-01-089-7399 1325-14-453-9451

Freight Information 1325-00-710-6765

1325-00-710-6765 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 064300. A Sub NMFC of A. It has a NMFC Description of EXPLOSIVES:AMMO OR CARTRIDGES SUB1. 1325-00-710-6765 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. 1325-00-710-6765 is rated as class 200 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 05980 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 423 for ocean manifesting and military sealift. 1325-00-710-6765 is classified as Explosive Class A, UN Class 1.1 or 1.2, when transported by water. 1325-00-710-6765 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air. This item is Hazardous and is described as "EXPLOSIVE BOMB CLASS A EXPLOSIVE".

Packaging Data 1325-00-710-6765

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Ammunition (Class V; Igloos and Magazines)

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 2; 99.0" H x 38.0" W x 24.3" L; --; --; --; Special Requirements

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Special Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; --

Intermediate Pack Level

Quantity of Unit Packs
Container: --
