1305-01-493-3632
5.56 Millimeter Cartridge
1305014933632 014933632 12991890 1305-AA69
Managed by United States
NSN Created on 2 Jan 2002
Data Last Changed
November 2023
November 2023
NATO Update Count
9
9
NATO Data Quality
Product Information 1305-01-493-3632
5.56 mm x 45
AP 3
M995
Significantly increases the warfighter’s lethality. Optimized projectile design with a tungsten carbide core for penetration of hard targets. Penetrates 12 mm rolled homogeneous armor 300 HB at 100 m and light body armor at normal combat distances
Projectile weight 3.4 g (52 grain)
Muzzle velocity 1 030 m/s
Maximum dispersion SD < 200 mm at 550 m
Penetration 12 mm RHA at 0˚ at 100 m
Service temperature -54°C to +52°C
Safety temperature -54°C to +71°C
Type classified by US Army in 1996 as M995. In service in several countries. Combat proven and in production
Marketplace 1305-01-493-3632
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 1305-01-493-3632 5+ Documents (More...)
12991890 1305-AA69 Managed by United States NSN Created on 2 Jan 2002 Data Last Changed November 2023
NATO Update Count 9 NATO Data Quality 1305-01-493-3632 Photo 1/1 1.
Combat proven and in production Marketplace 1305-01-493-3632 Need Help?
NATO Update Count 9 NATO Data Quality 1305-01-493-3632 Photo 1/1 1.
Combat proven and in production Marketplace 1305-01-493-3632 Need Help?
793-1501 Socket Head Cap Screw 1305-99-963-6120 https//www.nsnlookup.com /fsg-13/fsc-1305/us 1305-01-493-3632
5.56 Millimeter Cartridge 1305014933632 Jun 1974 1305-01-493-3632 https//www.nsnlookup.com /fsg
5.56 Millimeter Cartridge 1305014933632 Jun 1974 1305-01-493-3632 https//www.nsnlookup.com /fsg
Winchester Caliber .308 Cartridge 1305-14-467-2427 https//www.nsnlookup.com /fsg-13/fsc-1305/us 1305-01-493-3632
5.56 Millimeter Cartridge 1305014933632 www.nsnlookup.com /fsg-13 Ammunition, through 30mm (FSC
5.56 Millimeter Cartridge 1305014933632 www.nsnlookup.com /fsg-13 Ammunition, through 30mm (FSC
(Active) Secondary Buy RNCC 5 RNVC 2 DAC U AA69 https//www.nsnlookup.com /fsg-13/fsc-1305/us 1305-01-493-3632
5.56 Millimeter Cartridge 1305014933632 your Account Upgrade 1305-01-493-36325.56 Millimeter Cartridge1305014933632
014933632 12991890 1305-AA69 NumberManufacturerStatus12991890 19200 - Combat Capabilities Development
5.56 Millimeter Cartridge 1305014933632 your Account Upgrade 1305-01-493-36325.56 Millimeter Cartridge1305014933632
014933632 12991890 1305-AA69 NumberManufacturerStatus12991890 19200 - Combat Capabilities Development
00-474-6210 Guided Missile Propulsion Section 499300-101RNCC: 3 | RNVC: 2 | DAC: 2 9 Jun 1974 1305-01-493-3632
Restrictions 1305-01-493-3632
1305-01-493-3632 is a 5.56 Millimeter Cartridge that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is Ammunition or Explosive and is a US Munitions List or Commerce Control List Item where demilitarization is required. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1305-01-493-3632
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1305-01-493-3632
- US Army (A901)
- Effective Date:
- 1 Jan 2002
- US Navy (NGFF)
- Effective Date:
- 1 Apr 2004
- MOE Rule:
- WN01
- Effective Date:
- 1 Jul 2007
Approved Sources 1305-01-493-3632
- Part Number
- Manufacturer
- Status
- 12991890
- Manufacturer
- 19200 - Combat Capabilities Development (Active)
- Primary Buy
- Primary Buy
- 1305-AA69
- 99999 - Department Of Defense Ammunition (Active)
- NATO Reference
- NATO Reference
Datasheet 1305-01-493-3632
- Characteristic
- Specifications
- FIIG
- Specifications
- T007-B
- Dot Identification Number [DENN]
- Un0012
- Dot Proper Shipping Name [SHPN]
- Cartridges,Small Arms
- Dod Ammunition Code [DDAC]
- 1305-Aa69
- Dot Registration Code [DTRC]
- Ex1997060084a
- End Item Identification [AGAV]
- 1005-01-128-9936
- Cartridge Design Type [AHUF]
- Armor Piercing
- Cartridge Grouping Type [AHUG]
- Clipped
- Cartridge Model Number [AHUE]
- M995
- Cartridge Quantity [AHUH]
- 1680
- Hazardous Material Classification Code [HMCC]
- 1.4 Department Of Defense Hazard Class Division And S Storage Compatibility Group
- Net Explosive Weight [EXWT]
- 0.004043 Transportation Pounds And 0.000000 Storage Pounds
- Special Features [FEAT]
- Packed 10 Ctgs/10 Round Clip, 3 Clips/Carton;4 Cartons/Bandoleer,M8 With Magazine Filler;7 Bandoleers/Box,Ammunition,M2a1;2 Box,M2a1/Box,Wire-Bound
- Weapon For Which Designed [AHVQ]
- Rifle M16
Management Data 1305-01-493-3632
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Dec 2009
- Department of the Army (DA)
- EA
- Subscribe
- EA
- Mar 2007
- Department of the Navy (DN)
- EA
- Subscribe
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- R
- Refer To 1305-Aa69
- 1305-AA69
- R
Army
- Materiel Category and Inventory Manager:
- D
- Single Manager Ammunition
- Appropriation and Budget Activity:
- K
- Ammunition
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- YC
- Conventional Ammunition
Cartridge, 5.56mm, All Types
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 2T
- Issue, Repair, Requisition Restriction Code:
- BV
- Controlled ammunition item. Submit/refer requisitions to NOC IMSD. Centralized control for issue of controlled ammunition items
NATO Stock Numbers Related to 1305-01-493-3632
1305-17-117-9849 1305-17-111-1383 1305-13-113-9670 1305-25-151-3978 1305-32-077-6519 1305-14-336-7749 1305-14-336-7748 1305-99-933-9514 1305-21-895-5805 1305-19-000-8175 1305-13-118-0269 1305-47-000-1193 1305-99-724-3391 1305-99-811-9328 1305-22-622-8199 1305-17-107-1996 1305-21-902-6166 1305-17-116-1765
Freight Information 1305-01-493-3632
1305-01-493-3632 has freight characteristics.. 1305-01-493-3632 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 1305-01-493-3632
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Ammunition (Class V; Igloos and Magazines)
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 14.5" H x 12.8" W x 8.4" L
- --
- --
- --
- Special Requirements
- 14.5" H x 12.8" W x 8.4" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- Special Requirement
- Special Requirements – see Specific Instructions or Drawings provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special Requirements. See Specific Instructions or Drawings Provided
- Special requirement – See specific instructions or drawings provided
- --
- Special Requirements – see Specific Instructions or Drawings provided
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
