1285-00-187-6653

Radar Set Subassembly

1285001876653 001876653 2837437

Two or more different types of items, having a common mounting or mounted on each other, which together form a portion of a radar set, but, which in itself is not a complete functioning item and cannot be assigned a more definite item name. View more Radar Set Subassembly

Managed by United States

NSN Created on 14 Mar 1973

Data Last Changed
May 2023

NATO Update Count
5

NATO Data Quality

1285-00-187-6653 RADAR SET SUBASSEMBLY 1285001876653 001876653 1/2 — 1285-00-187-6653 Photo 1/2

1285-00-187-6653 RADAR SET SUBASSEMBLY 1285001876653 001876653 2/2 — 1285-00-187-6653 Photo 2/2

Marketplace 1285-00-187-6653

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

2837437 RADAR SET SUBASSEMBLY 1 EA NS

Updated Every Day

1285-00-187-6653 RQST NE

Restrictions 1285-00-187-6653

IUID Required

1285-00-187-6653 is a Radar Set Subassembly that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1285-00-187-6653

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1285-00-187-6653

US Navy (N2H4)
Effective Date:: 1 Apr 1991
Supplementary Receivers:: GG; AMC 1 AMSC G AMSC V IMC E IMCACTY HD

Germany (ZG01)
Effective Date:: 1 Apr 1991

Approved Sources 1285-00-187-6653

Part Number
Manufacturer
Status
2837437: 10001 - Navair And Navsea Managed Original (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1

Datasheet 1285-00-187-6653

Characteristic
Specifications
FIIG: A511L0
Overall Height [ABKW]: 0.892 Inches Nominal
Overall Length [ABHP]: 5.100 Inches Nominal
Overall Width [ABMK]: 4.575 Inches Nominal
Special Features [FEAT]: Major Component And Quantity: Ampilifier; Bracket; Capacitor; Connector; Diode; Dissipator; Printed Wiring Board; Resistor; Spreader; Switch; Transistor; 107; Mounting Method: Connector

Management Data 1285-00-187-6653

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe
Oct 2021: Department of the Navy (DN); EA; Subscribe
Oct 2020: Department of the Navy (DN); EA; Subscribe
Nov 2019: Department of the Navy (DN); EA; Subscribe

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Navy (DN): L; R; Refer To Net Price 1709.00; NET PRICE 1709.00

Navy

Cognizance:

7H

Issue, Repair, Requisition Restriction Code:

00: No Restriction

Special Material Content:

3: Electrostatic Discharge (ESD)/Sensitive Item

Similar Supply Items to 1285-00-187-6653

Freight Information 1285-00-187-6653

1285-00-187-6653 has freight characteristics managed by the Office od the Secretary of HEW.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of Z. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 1285-00-187-6653 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 1285-00-187-6653 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 1285-00-187-6653 is not classified as a special type of cargo when transported by water. 1285-00-187-6653 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
