1270-01-393-2380
Rotary Electro-Mechanical Actuator
1270013932380 013932380 717513600-001 87400000-02
A self-contained power transmitting device designed to convert electrical energy into controlled mechanical force, in the form of torque (rotational mechanical movement). Comprised of an electric motor(s), gear box(es), limit switch(es), and such accessories as required for the specific moving and positioning of other components. Excludes hydraulic and pneumatic cylinders and screwjacks. View more Rotary Electro-Mechanical Actuator
May 2023
10
Marketplace 1270-01-393-2380
Request a Quotation from participating marketplace vendors
Related Documents 1270-01-393-2380 4+ Documents (More...)
Photo 1/5 1270-01-393-2380 Photo 2/5 1270-01-393-2380 Photo 3/5 1270-01-393-2380 Photo 4/5 1270
United States (US) 4. 1270-01-393-2380 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 1270-01-393-2380
IUID Required
1270-01-393-2380 is a Rotary Electro-Mechanical Actuator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item is not suspected to be hazardous. This item does not contain a precious metal. This item is sensitive to Electrostatic Discharge.
Import and Export 1270-01-393-2380
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1270-01-393-2380
- US Air Force (FGG4)
- Effective Date:
- 28 Jun 2003
- US Air Force (FMSG)
- Effective Date:
- 1 Sep 2015
- Israel (YD01)
- Effective Date:
- 1 Mar 2002
Approved Sources 1270-01-393-2380
- Part Number
- Manufacturer
- Status
- 717513600-001
- Manufacturer
- 04939 - Lockheed Martin Corporation (Active)
- Reparable Source Control
- Reparable Source Control
- 87400000-02
- 1K426 - Moog Inc. (Active)
- Primary Reparable
- Primary Reparable
Datasheet 1270-01-393-2380
- Characteristic
- Specifications
- FIIG
- Specifications
- A30500
- Drive Type [AKCV]
- Direct
- Duty Cycle [AKPS]
- Variable
- Current Type [ACDC]
- Dc
- End Item Identification [AGAV]
- Roll Section, Lantirn Tgt Pod
- Limit Switch Control [AWQN]
- Not Included
- Manual Override [AWQR]
- Not Included
- Reference Number Differentiating Characteristics [ZZZY]
- Actuator 01/02
- Shaft Rotation Direction [AKCT]
- Clockwise And Counterclockwise
- Special Features [FEAT]
- Deroll Actuator Assembly
- Terminal Type [AARB]
- Connector
Management Data 1270-01-393-2380
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Nov 2016
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Similar Supply Items to 1270-01-393-2380
Freight Information 1270-01-393-2380
1270-01-393-2380 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of F. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 1270-01-393-2380 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 1270-01-393-2380 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 1270-01-393-2380 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 1270-01-393-2380 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1270-01-393-2380
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- 5.0" H x 3.3" W x 2.5" L
- --
- Electrical Instrument
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- 8.3" H x 8.3" W x 12.5" L
- --
- --
- --
- Any Suitable Process
- 8.3" H x 8.3" W x 12.5" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- PPP-B-1672, Type I, Vertical Star Cushioning in Reusable Box
- ESD sensitive electronic device requirements of MIL-STD-129 apply
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
