1240-00-895-6492

Telescope Mount

1240008956492 008956492 8587295

A mechanical device designed to support and/or position a telescope. It may include one or more of the following; cross leveling device, means of boresighting a gun, azimuth and/or elevation, adjusting mechanism, and accommodations for attaching a LIGHT, INSTRUMENT. View more Telescope Mount

Managed by United States

NSN Created on 1 Jan 1962

Data Last Changed
May 2023

NATO Update Count
23

NATO Data Quality

1240-00-895-6492 MOUNT,TELESCOPE 1240008956492 008956492 1/1 — 1240-00-895-6492 Photo 1/1

Marketplace 1240-00-895-6492

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

1240-00-895-6492 RQST NE

Restrictions 1240-00-895-6492

1240-00-895-6492 is a Telescope Mount Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1240-00-895-6492

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1240-00-895-6492

US Army (A402)
Effective Date:: 1 Apr 1991; AMC 1 AMSC G AMSC A IMC E IMCACTY BF DSOR AI

Austria (WB01)
Effective Date:: 1 Feb 2005

Brazil (YA01)
Effective Date:: 1 Mar 2001

Spain (YB01)
Effective Date:: 1 Oct 1998

Morocco (YP01)
Effective Date:: 1 Jul 2010

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Nov 1998

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Sep 2001

Approved Sources 1240-00-895-6492

Part Number
Manufacturer
Status
8587295: 19200 - Combat Capabilities Development (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
1240008956492: A00AM - E.C.A Etablissement Central Des (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 1240-00-895-6492

Characteristic
Specifications
FIIG: T271-N
Elevation Adjustment Mechanism [BPDY]: Provided
End Item Identification [AGAV]: Mount,Telescope M137
Azimuth Adjustment Mechanism [BPDX]: Provided
Instrument Light Accommodation [BPDZ]: Not Provided

Management Data 1240-00-895-6492

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Army (DA); EA; Subscribe; 1
Oct 2020: Department of the Army (DA); EA; Subscribe; 1
Oct 2019: Department of the Army (DA); EA; Subscribe; 1
Jun 2014: US Marine Corps (DM); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): L; R; Refer To Net Price 5059.00; NET PRICE 5059.00

Army

Materiel Category and Inventory Manager:

M: Ammunition weapons, and tracked combat vehicles weapons, special weapons, chemical and fire control materiel

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

KD: Combat Vehicles
Gun, Field Artillery Self-propelled 175mm M107, Howitzer 8-Inch M110

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Marine Corps

Stores Account:

2: Appropriation Stores Account Secondary Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

12

Material Identification:

S: Maintenance Float Secondary Depot Reparables

Operational Test:

0

Similar Supply Items to 1240-00-895-6492

Freight Information 1240-00-895-6492

1240-00-895-6492 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 146450. A Sub NMFC of X. It has a NMFC Description of MOUNTS FOR SIGHTING EQUIP. 1240-00-895-6492 is rated as class 85 when transported by Less-Than Truckload (LTL) freight. 1240-00-895-6492 is rated as class 85 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 73140 which rates the freight between FCL and LCL. 1240-00-895-6492 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 576 for ocean manifesting and military sealift. 1240-00-895-6492 is not classified as a special type of cargo when transported by water. 1240-00-895-6492 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 1240-00-895-6492

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Unheated General Purpose

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 19.8" H x 19.2" W x 15.4" L; --; --; --; Special Requirements

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: Special Requirement; Special Requirements – see Specific Instructions or Drawings provided; Special Requirements. See Specific Instructions or Drawings Provided; Special Requirements. See Specific Instructions or Drawings Provided; Special requirement – See specific instructions or drawings provided; --

Intermediate Pack Level

Quantity of Unit Packs
Container: --
