1240-00-302-1403
Optical Element Cell
1240003021403 003021403 8201260
A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position. View more Optical Element Cell
May 2023
16
Marketplace 1240-00-302-1403
Request a Quotation from participating marketplace vendors
Related Documents 1240-00-302-1403 1+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Updated Every Day 1240-00-302-1403
RQST NE Updated Every Day 1240-00-302-1403 RQST Updated Every Day 1240-00-302-1403 RQST NE Restrictions
Restrictions 1240-00-302-1403
1240-00-302-1403 is a Optical Element Cell that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 1240-00-302-1403
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1240-00-302-1403
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Apr 2002
Approved Sources 1240-00-302-1403
- Part Number
- Manufacturer
- Status
- 8201260
- Manufacturer
- 19200 - Combat Capabilities Development (Active)
- Primary Buy
- Primary Buy
Datasheet 1240-00-302-1403
- Characteristic
- Specifications
- FIIG
- Specifications
- T271-J
- Drive Type [AKCV]
- Slotted Face
- Eccentric Construction [BMTZ]
- Not Provided
- Element Securing Method [BPDF]
- Threaded Ring
- Chamfer Location [BPDC]
- Opposite Drive End
- Chamfer Size [BPDD]
- 1/32 In. By 45 Deg
- Material [MATT]
- Aluminum Alloy 2024
- Fsc Application Data [ZZZV]
- 1. Range Finder M13
- Screw Thread Series Designator [AJYP]
- Uns
- Overall Diameter [ADAV]
- 2.093 Inches Nominal
- Overall Height [ABKW]
- 0.812 Inches Nominal
- Thread Length [ABET]
- 0.312 Inches
- Thread Location [APJC]
- Internal
- Thread Size [ABUJ]
- 1-3/4 In. - 32
- Thread Class [AAJD]
- 2
NATO Stock Numbers Related to 1240-00-302-1403
Freight Information 1240-00-302-1403
1240-00-302-1403 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058110. A Sub NMFC of X. It has a NMFC Description of OPTICAL GOODS OR INSTRUMENTS NOI. 1240-00-302-1403 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. 1240-00-302-1403 is rated as class 200 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 33110 which rates the freight between FCL and LCL. 1240-00-302-1403 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 744 for ocean manifesting and military sealift. 1240-00-302-1403 is not classified as a special type of cargo when transported by water. 1240-00-302-1403 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
