1240-00-302-1360
Optical Element Cell
1240003021360 003021360 8200357
A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position. View more Optical Element Cell
May 2023
20
Marketplace 1240-00-302-1360
Request a Quotation from participating marketplace vendors
Related Documents 1240-00-302-1360 1+ Documents (More...)
United States (US) 4. 1240-00-302-1360 Marketplace Restrictions Approved Sources Datasheet Management
CELL,OPTICAL ELEMENT RQST NS Request Quotation Updated Every Day 1240-00-302-1360 RQST NE Updated
Restrictions 1240-00-302-1360
1240-00-302-1360 is a Optical Element Cell that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 1240-00-302-1360
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1240-00-302-1360
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Apr 2002
Approved Sources 1240-00-302-1360
- Part Number
- Manufacturer
- Status
- 8200357
- Manufacturer
- 19200 - Combat Capabilities Development (Active)
- Primary Buy
- Primary Buy
Datasheet 1240-00-302-1360
- Characteristic
- Specifications
- FIIG
- Specifications
- T271-J
- Drive Type [AKCV]
- Drilled Hole
- Eccentric Construction [BMTZ]
- Not Provided
- Element Securing Method [BPDF]
- Threaded Ring
- Chamfer Location [BPDC]
- Drive End
- Chamfer Size [BPDD]
- 0.067 In. By 45 Deg
- Material [MATT]
- Aluminum Alloy 2011
- Screw Thread Series Designator [AJYP]
- Uns And Uns
- Overall Diameter [ADAV]
- 1.625 Inches Nominal
- Overall Height [ABKW]
- 0.709 Inches Nominal
- Thread Length [ABET]
- 0.105 Inches And 0.455 Inches
- Thread Location [APJC]
- Internal And External
- Thread Size [ABUJ]
- 1-1/2 - 32 And 1-5/8 In. - 32
- Thread Class [AAJD]
- 2B And 2A
Similar Supply Items to 1240-00-302-1360
Freight Information 1240-00-302-1360
1240-00-302-1360 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058110. A Sub NMFC of X. It has a NMFC Description of OPTICAL GOODS OR INSTRUMENTS NOI. 1240-00-302-1360 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. 1240-00-302-1360 is rated as class 200 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 33110 which rates the freight between FCL and LCL. 1240-00-302-1360 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 744 for ocean manifesting and military sealift. 1240-00-302-1360 is not classified as a special type of cargo when transported by water. 1240-00-302-1360 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
