1240-00-210-4393

Optical Element Cell

1240002104393 002104393 1262789 789PC2

A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position. View more Optical Element Cell

1240-00-210-4393 CELL,OPTICAL ELEMENT 1240002104393 002104393

Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
May 2023
NATO Update Count
8
NATO Data Quality
1240-00-210-4393 CELL,OPTICAL ELEMENT 1240002104393 002104393 1/4
1240-00-210-4393 Photo 1/4
1240-00-210-4393 CELL,OPTICAL ELEMENT 1240002104393 002104393 2/4
1240-00-210-4393 Photo 2/4
1240-00-210-4393 CELL,OPTICAL ELEMENT 1240002104393 002104393 3/4
1240-00-210-4393 Photo 3/4
1240-00-210-4393 CELL,OPTICAL ELEMENT 1240002104393 002104393 4/4
1240-00-210-4393 Photo 4/4

1240-00-210-4393 Stock and Availability Marketplace 1240-00-210-4393

Need Help?
Request a Quotation from participating marketplace vendors

1240-00-210-4393 Related Documents Related Documents 1240-00-210-4393 4+ Documents (More...)

1262789 789PC2 A cylindrical item specifically designed to hold a lens, reticle, or window in an optical
Photo 1/4 1240-00-210-4393 Photo 2/4 1240-00-210-4393 Photo 3/4 1240-00-210-4393 Photo 4/4 - -
United States (US) 4. 1240-00-210-4393 Marketplace Restrictions Approved Sources Datasheet Management
enable JavaScript in your web browser . 5930-25-135-0359Termostat5930251350359 251350359 TM1W6 3-789PC2
www.nsnlookup.com /fsg-59/fsc-5930/no 5930-25-135-0359 Termostat 5930251350359251350359,TM1W6 TM1W63-789PC2
Optical Element Cell 1240002104393 002104393 ) https//www.nsnlookup.com /fsg-12/fsc-1240/us https
Similar Supply Items to 1240-00-157-9669 1240-00-153-2353 1240-00-159-0513 1240-00-302-1360 1240-00-210-4393
Right-Hand And Right-Hand Similar Supply Items to 1240-00-159-0513 1240-00-153-2353 1240-00-302-1360 1240-00-210-4393

1240-00-210-4393 Demil Restrictions 1240-00-210-4393

DEMIL: D | DEMILI: | CRITICALITY: X | HMIC: N | PMIC: A | EDC: | ADPEC: 0

1240-00-210-4393 is a Optical Element Cell that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

1240-00-210-4393 HTS and ScheduleB Import and Export 1240-00-210-4393

1240-00-210-4393 End Users End Users 1240-00-210-4393

Spain (YB01)
Effective Date:
1 Apr 1991
Turkey (ZW01)
Effective Date:
1 Nov 1998

1240-00-210-4393 Manufacturers Approved Sources 1240-00-210-4393

1240-00-210-4393 Technical Data Datasheet 1240-00-210-4393

Characteristic
Specifications
FIIG
T271-J
Drive Type [AKCV]
Drilled Hole
Eccentric Construction [BMTZ]
Provided
Element Securing Method [BPDF]
External Thread
Cell Eccentricity From Geometric Axis [BMWB]
0.001 Inches
Chamfer Location [BPDC]
Threaded End
Material [MATT]
Aluminum Alloy
Screw Thread Series Designator [AJYP]
Uns And Uns
Overall Diameter [ADAV]
2.250 Inches Nominal
Overall Length [ABHP]
1.836 Inches Nominal
Thread Length [ABET]
0.300 Inches And 0.376 Inches
Thread Location [APJC]
Internal And External
Thread Pitch Diameters [AAJE]
+1.8547 To 1.8600 Inches And +2.0679 To 2.0721 Inches
Thread Size [ABUJ]
1 7/8-32 And 2 5/64-32
Thread Class [AAJD]
2B And 2A
Thread Direction [AAJF]
Right-Hand And Right-Hand

1240-00-210-4393 Similar Items Similar Supply Items to 1240-00-210-4393

1240-00-210-4393 Freight Data Freight Information 1240-00-210-4393

1240-00-210-4393 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058110. A Sub NMFC of X. It has a NMFC Description of OPTICAL GOODS OR INSTRUMENTS NOI. 1240-00-210-4393 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33110 which rates the freight between FCL and LCL. 1240-00-210-4393 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 653 for ocean manifesting and military sealift. 1240-00-210-4393 is not classified as a special type of cargo when transported by water. 1240-00-210-4393 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

1240-00-210-4393 Packaging Data Packaging Data 1240-00-210-4393

Responsible Activity
Packaging Data Source
Primary Inventory Control Activity (PICA)
--

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
--
--
--
0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
85 to 110G
No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
--
--
--
--
--
Any Suitable Process
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
No Requirement
No Requirement
PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
--
PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container
Any Suitable Fiber Box
