1240-00-159-0513
Optical Element Cell
1240001590513 001590513 654768 265606
A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position. View more Optical Element Cell
May 2023
22
Marketplace 1240-00-159-0513
Request a Quotation from participating marketplace vendors
Related Documents 1240-00-159-0513 4+ Documents (More...)
United States (US) 4. 1240-00-159-0513 Marketplace Restrictions Approved Sources Datasheet Management
CELL,OPTICAL ELEMENT 250 EA NS Request Quotation Updated Every Day 1240-00-159-0513 RQST NE Related
Optical Element Cell 1240001590513 001590513 Documents 1240-00-159-0513 3+ Documents ( More...
$1 a day Upgrade your Account Upgrade 7021-01-618- 6240Computer Subassembly7021016186240 016186240 654768
$1 a day Upgrade your Account Upgrade 7021-01-618-6240Computer Subassembly7021016186240 016186240 654768
Optical Element Cell 1240001590513 001590513 $1 a day Upgrade your Account Upgrade 1240-00-159-
www.nsnlookup.com /fsg-41/fsc-4140/us 4140-01-530-5973 https//www.nsnlookup.com /fsg-12/fsc-1240/us 1240-00-159-0513
Optical Element Cell 1240001590513 001590513 day Upgrade your Account Upgrade 1240-00-159-0513Optical
Restrictions 1240-00-159-0513
1240-00-159-0513 is a Optical Element Cell that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1240-00-159-0513
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1240-00-159-0513
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 1240-00-159-0513
- Part Number
- Manufacturer
- Status
- 654768
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 265606
- 56232 - Lockheed Martin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 1240-00-159-0513
- Characteristic
- Specifications
- FIIG
- Specifications
- T271-J
- Drive Type [AKCV]
- Slotted Face
- Eccentric Construction [BMTZ]
- Not Provided
- Element Securing Method [BPDF]
- Internal Thread
- Chamfer Location [BPDC]
- Drive End
- End Item Identification [AGAV]
- Gun Sight Mk29 Mod1
- Material [MATT]
- Aluminum Alloy
- Screw Thread Series Designator [AJYP]
- Uns And Uns
- Overall Diameter [ADAV]
- 1.750 Inches Nominal
- Overall Length [ABHP]
- 0.968 Inches Nominal
- Thread Length [ABET]
- 0.563 Inches And 0.343 Inches
- Thread Location [APJC]
- External And Internal
- Thread Size [ABUJ]
- 1 3/4-32 And 1 1/2-32
- Thread Class [AAJD]
- 2A And 2B
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
NATO Stock Numbers Related to 1240-00-159-0513
Freight Information 1240-00-159-0513
1240-00-159-0513 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 058110. A Sub NMFC of X. It has a NMFC Description of OPTICAL GOODS OR INSTRUMENTS NOI. 1240-00-159-0513 is rated as class 200 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 33110 which rates the freight between FCL and LCL. 1240-00-159-0513 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 1240-00-159-0513 is not classified as a special type of cargo when transported by water. 1240-00-159-0513 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1240-00-159-0513
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Plated/Coated Item
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- 1.8" H x 1.8" W x 1.0" L
- --
- --
- Physical Protection
- Any Suitable Process
- 1.8" H x 1.8" W x 1.0" L
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-203, Kraft Wrapping Paper
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- A-A-203, Kraft Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
