1240-00-153-2353
Optical Element Cell
1240001532353 001532353 689190 822607
A cylindrical item specifically designed to hold a lens, reticle, or window in an optical system. Includes eccentric cells and/or rings designed to be rotated within the instrument to shift an optical element to a prescribed position. View more Optical Element Cell
May 2023
18
Marketplace 1240-00-153-2353
Request a Quotation from participating marketplace vendors
Related Documents 1240-00-153-2353 5+ Documents (More...)
Photo 1/2 1240-00-153-2353 Photo 2/2 - - 1.
United States (US) 4. 1240-00-153-2353 Marketplace Restrictions Approved Sources Datasheet Management
... ) https//www.nsnlookup.com /fsg-66/fsc-6685/nl 6685-17-118-95886685171189588 171189588,689190 689190
Optical Element Cell 1240001532353 001532353 $1 a day Upgrade your Account Upgrade 1240-00-153-
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 822607
www.nsnlookup.com /fsg-66/fsc-6680/us 6680-00-580-4381 https//www.nsnlookup.com /fsg-12/fsc-1240/us 1240-00-153-2353
/fsg-53/fsc-5330/us
vendors Request FedMall Updated Every 15 Minutes 5330-01-116-7969 BUY NE FedMall Updated Every Day 689190
https//www.nsnlookup.com /fsg-53/fsc-5330/us 5330-01-116-7969 Seal 5330011167969 011167969,689190 C1 689190
web browser . 6685-17-118-9588Electrical Resistance Temperature Transmitter6685171189588 171189588 689190
... ) https//www.nsnlookup.com /fsg-66/fsc-6685/nl 6685-17-118-95886685171189588 171189588,689190 689190
Restrictions 1240-00-153-2353
1240-00-153-2353 is a Optical Element Cell that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List Item and must be mutilated to scrap. This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1240-00-153-2353
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1240-00-153-2353
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 1240-00-153-2353
- Part Number
- Manufacturer
- Status
- 689190
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 822607
- 56232 - Lockheed Martin Corporation (Active)
- Secondary Buy
- Secondary Buy
Datasheet 1240-00-153-2353
- Characteristic
- Specifications
- FIIG
- Specifications
- T271-J
- Eccentric Construction [BMTZ]
- Not Provided
- Chamfer Location [BPDC]
- Threaded End
- Chamfer Size [BPDD]
- 0.075 In. By 45 Deg
- End Item Identification [AGAV]
- Gun Sight Mk29
- Material [MATT]
- Aluminum
- Screw Thread Series Designator [AJYP]
- Uns And Uns
- Overall Height [ABKW]
- 0.050 Inches Minimum And 0.060 Inches Maximum
- Overall Length [ABHP]
- 0.250 Inches Minimum And 0.260 Inches Maximum
- Overall Width [ABMK]
- 2.057 Inches Minimum And 2.067 Inches Maximum
- Thread Length [ABET]
- 0.115 Inches And 0.145 Inches
- Thread Location [APJC]
- Internal And External
- Thread Size [ABUJ]
- 1.820-32 And 2.250-32
- Thread Class [AAJD]
- 2B And 2A
- Thread Direction [AAJF]
- Right-Hand And Right-Hand
Similar Supply Items to 1240-00-153-2353
Freight Information 1240-00-153-2353
1240-00-153-2353 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of J. It has a NMFC Description of HARDWARE, NOI SUB 9. 1240-00-153-2353 is rated as class 70 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 1240-00-153-2353 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 1240-00-153-2353 is not classified as a special type of cargo when transported by water. 1240-00-153-2353 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1240-00-153-2353
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
