1220-00-624-8452

Board Assy

1220006248452 006248452 BUWEPSDWG1835912 316474 1835912

INC: 77777

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
May 2023

NATO Update Count
8

NATO Data Quality

1220-00-624-8452 BOARD ASSY 1220006248452 006248452 1/1 — 1220-00-624-8452 Photo 1/1

Marketplace 1220-00-624-8452

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

2075655 BOARD ASSY 192 EA NS

Updated Every Day

1220-00-624-8452 RQST NE

Restrictions 1220-00-624-8452

IUID Required

1220-00-624-8452 is a Board Assy that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1220-00-624-8452

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1220-00-624-8452

US Navy (N2H4)
Effective Date:: 1 Apr 1991
Supplementary Receivers:: GG; AMC 1 AMSC G AMSC V IMC E IMCACTY HD

Spain (YB01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 May 2005

Turkey (ZW01)
Effective Date:: 1 Nov 1998

Approved Sources 1220-00-624-8452

Part Number
Manufacturer
Status
BUWEPSDWG1835912: 36090 - Lockheed Martin Librascope (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
316474: 36090 - Lockheed Martin Librascope (Active); Primary Buy; RNCC 3 RNVC 2 DAC X
1835912: 10001 - Navair And Navsea Managed Original (Active); Original Design; RNCC 3 RNVC 9 DAC 5

Datasheet 1220-00-624-8452

Characteristic
Specifications
FIIG: A23900
End Item Identification [AGAV]: Fire Control Computing Sights And Devices

Management Data 1220-00-624-8452

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Navy (DN); EA; Subscribe
Oct 2021: Department of the Navy (DN); EA; Subscribe
Oct 2020: Department of the Navy (DN); EA; Subscribe
Nov 2019: Department of the Navy (DN); EA; Subscribe

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Navy (DN): L; R; Refer To Net Price 498.00; NET PRICE 498.00

Navy

Cognizance:

7H

Issue, Repair, Requisition Restriction Code:

00: No Restriction

Special Material Content:

3: Electrostatic Discharge (ESD)/Sensitive Item

Similar Supply Items to 1220-00-624-8452

Freight Information 1220-00-624-8452

1220-00-624-8452 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 116030. A Sub NMFC of Z. It has a NMFC Description of MACHINES ETC DATA PROCESSING. 1220-00-624-8452 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 59295 which rates the freight between FCL and LCL. 1220-00-624-8452 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 1220-00-624-8452 is not classified as a special type of cargo when transported by water. 1220-00-624-8452 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 1220-00-624-8452

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); Packaging Data does not meet current MIL-STD-2073-1E

Storage Environment: Unheated General Purpose

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: --; 12.0" H x 5.0" W x 1.3" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag; PPP-C-795, Class 2, Antistatic Cellular Plastic Film Cushioning; 1/2 inch thick; ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box; ESD sensitive electronic device requirements of MIL-STD-129 apply

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
