1080-01-475-0697

Ultralight Weight Camouflage Net System

1080014750697 014750697 191259-0001 AN/USQ-160

A collection of concealment systems, each consisting of a camouflage net system made up of hexagon and rhombic shaped screens, a screen repair kit and carrying case. A support system; stakes, support poles, ahape disruptors and carrying case used to reduce the visual, electro-optic, and infrared signature characteristics of tactically deployed aviation and ground radar equipment. The collection of camouflage nets are radar transparent and may not be limited to ultralight weight and are snag resistant. Variants included but are not limited to woodlands, desert, arctic, and urban configurations. View more Radar Transparent Camouflage Net System

Managed by United States

NSN Created on 20 May 2000

Data Last Changed
October 2023

NATO Update Count
18

NATO Data Quality

1080-01-475-0697 CAMOUFLAGE NET SYSTEM,ULTRALIGHT WEIGHT 1080014750697 014750697 1/1 — 1080-01-475-0697 Photo 1/1

Product Information 1080-01-475-0697

ULCAS Ultra-Lightweight Camouflage Screen

The Ultra-Lightweight Camouflage Screen (ULCAS) is designed to camouflage deployed assets ranging from groups of personnel to static vehicles and command posts. Patterns, colours and a 3D structure are used to mimic the background of the surrounding terrain, while special pigments help the system to avoid detection by near infrared and short-wave infrared sensors. It also protects against radar reconnaissance and homing missiles in the 1–100 GHz range.

Marketplace 1080-01-475-0697

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

1080-01-475-0697 RQST NE

Restrictions 1080-01-475-0697

1080-01-475-0697 is a Ultralight Weight Camouflage Net System that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1080-01-475-0697

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1080-01-475-0697

US Army (A502)
Effective Date:: 1 May 2000; AMC 0 AMSC 0 AMSC A IMC E DSOR TB

US Air Force (F5CL)
Effective Date:: 1 Aug 2003; AMC 0 AMSC 0 AMSC 6 IMC E DSOR 00

US Marine Corps (MA46)
Effective Date:: 1 Nov 2002; AMC 0 AMSC 0 AMSC 6 IMC E DSOR 00

Slovenia (WL01)
Effective Date:: 1 Sep 2013

Spain (YB01)
Effective Date:: 1 Jun 2004

Singapore (YJ01)
Effective Date:: 1 Jun 2004

Republic of Korea (ZH01)
Effective Date:: 1 Jun 2004

Denmark (ZS01)
Effective Date:: 1 Sep 2014

Turkey (ZW01)
Effective Date:: 1 Dec 2005

Approved Sources 1080-01-475-0697

Part Number
Manufacturer
Status
191259-0001: 1X5J9 - Saab Barracuda Llc (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1
AN/USQ-160: 80058 - Joint Electronics Type Designation (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
191259-0001: 0V8C5 - Gma Cover Corp. (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
191259-0001: 19397 - Bae Systems Information & Electronic (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5

Datasheet 1080-01-475-0697

Characteristic
Specifications
FIIG: A23800
End Item Identification [AGAV]: Forklift Truck,Smith Corporation,Model 12, Type A

Management Data 1080-01-475-0697

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Mar 2023: US Marine Corps (DM); EA; Subscribe; 1
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Nov 2020: Department of the Army (DA); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Mar 2020: US Marine Corps (DM); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): L; R; Refer To Net Price 3351.00; NET PRICE 3351.00
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 1080-00-107-8293
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 1080-00-107-8563
US Marine Corps (DM): M; 0; Reversal Of Phrase Code Z 1080-00-107-8580

Army

Materiel Category and Inventory Manager:

G: Communications and Electronics Equipment, Electronics Materiel

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

UT: POL, Soldier and Combat Support System
Counter Surveillance Systems

Accounting Requirements:

N: Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.

Air Force

Fund:

SF: Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point

Budget:

9: 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors

Aggregation Code:

GG: GUNNERY EQUIPMENT

Price Validation Code:

V: The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.

Expendability Recoverability Repairability:

N: Expendable. Condemn at User. Stock Fund (except Munitions).

Marine Corps

Stores Account:

1: Stock Fund Account Item

Combat Essentiality:

1: Combat Essential End Item

Echelon Management:

11

Material Identification:

U: Organizational Clothing/Equipment

Operational Test:

0

NATO Stock Numbers Related to 1080-01-475-0697

1080-33-209-2553 1080-01-562-5596 1080-01-677-6918 1080-01-573-6419 1080-01-564-1690 1080-01-618-1655 1080-33-209-2552 1080-01-559-3173 1080-01-475-0697 1080-01-475-0694

Freight Information 1080-01-475-0697

1080-01-475-0697 has freight characteristics.. 1080-01-475-0697 has a variance between NMFC and UFC when transported by rail and the description should be consulted.

Packaging Data 1080-01-475-0697

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Storage Environment: Heated General Purpose – Heated 40 F and above

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 52.0" H x 24.0" W x 19.0" L; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 53.0" H x 25.0" W x 20.0" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; ASTM-D5118, Type CF, Class Weather-Resistant, Double Wall, Corrugated Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: No Requirement
