1055-00-953-9791

Grenade Launcher Barrel

1055009539791 009539791 7791569

INC: 21719 Grenade Launcher Barrel

Managed by United States

NSN Created on 1 Jan 1962

Data Last Changed
June 2023

NATO Update Count
25

NATO Data Quality

1055-00-953-9791 BARREL,GRENADE LAUNCHER 1055009539791 009539791 1/1 — 1055-00-953-9791 Photo 1/1

Marketplace 1055-00-953-9791

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

1055-00-953-9791 BARREL,GRENADE LAUNCHER RQST NS

Updated Every Day

1055-00-953-9791 RQST NE

Restrictions 1055-00-953-9791

1055-00-953-9791 is a Grenade Launcher Barrel that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 1055-00-953-9791

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 1055-00-953-9791

US Army (A920)
Effective Date:: 1 Jun 2006
Former MOE Rule:: A181
Supplementary Receivers:: AZCNBF; AMC 1 AMSC G IMC Z IMCACTY CD

US Air Force (FGGC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: FGAX; AMC 1 AMSC G IMC Z IMCACTY TG

US Marine Corps (MC40)
Effective Date:: 1 Jun 2006
Former MOE Rule:: MC01; AMC 1 AMSC G IMC Z IMCACTY PA

US Navy (N9BC)
Effective Date:: 1 Jun 2006
Former MOE Rule:: N9CD; AMC 1 AMSC G IMC Z IMCACTY GH

Austria (WB01)
Effective Date:: 1 Feb 2005

Thailand (YY01)
Effective Date:: 1 Feb 2015

Australia (ZA01)
Effective Date:: 1 Apr 1991

New Zealand (ZE01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Apr 2002

Approved Sources 1055-00-953-9791

Part Number
Manufacturer
Status
7791569: 19204 - Army, United States Department Of (Active); Primary Buy; RNCC 3 RNVC 2 DAC 1

Datasheet 1055-00-953-9791

Characteristic
Specifications
FIIG: T102-G
Caliber Quantity Per Rifling Turn [ANBZ]: 1 Turn In 30.480 Calibers
Groove Width [ABGF]: 0.694 Inches Minimum And 0.701 Inches Maximum
End Item Identification [AGAV]: 1010-691-1382 M79
Material [MATT]: Aluminum
Fsc Application Data [ZZZV]: Launcher,Grenade,40Mm
Weapon Model Number [ANLB]: M79
Weapon Size Designation [ANLA]: 40 Millimeter
Inside Surface Treatment [AAJQ]: Anodized, Mil-A-8625, Type 3, Class 1
Land Width [ANBS]: 0.133 Inches Nominal
Rifle Bore Groove Quantity [ANBR]: 6
Rifling Direction [ANBT]: Right-Hand
Size Designation [ALJP]: 40 Millimeter
Overall Length [ABHP]: 13.985 Inches Minimum And 14.045 Inches Maximum
Special Features [FEAT]: Elongation,5 Percent Minimum Yield Strength 65000 Psi
Surface Treatment [SFTT]: Anodize

Weapon Systems (WSDC) 1055-00-953-9791

Subscribe
View WSDC

Subscribe to View Weapon System Codes...

Subscribe
View Data

DLA Procurement Analysis 1055-00-953-9791

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 1055-00-953-9791

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Army (DA); EA; Subscribe; 1
Oct 2021: Department of the Navy (DN); EA; Subscribe; 1
Oct 2020: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

Army

Materiel Category and Inventory Manager:

J: Ground Forces Support Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 1055-00-953-9791

Freight Information 1055-00-953-9791

1055-00-953-9791 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 091720. A Sub NMFC of X. It has a NMFC Description of GUN BARRELS STEEL NOI IN BOXES. 1055-00-953-9791 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 1055-00-953-9791 is rated as class 100 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 48170 which rates the freight between FCL and LCL. It has a Water Commodity Code (WCC) of 685 for ocean manifesting and military sealift. 1055-00-953-9791 is not classified as a special type of cargo when transported by water. 1055-00-953-9791 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 1055-00-953-9791

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; Bare Metal Item; Over 10lb; Less than 85G; Special Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: Any Suitable Fiber Box
