1005-00-556-4102
Small Arms Cleaning Rod
1005005564102 005564102 5564102 RTI-1600 A10230 F1232C 1005-556-4102 1005PL0902408
A cylindrical body used with a brush or cloth (swab), or other attachment, for cleaning the bore of a small arms firearm. See also STAFF SECTION, CLEANING, ARTILLERY. Excludes ROD SECTION, CLEANING, SMALL ARMS. View more Small Arms Cleaning Rod
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
61
61
NATO Data Quality
Marketplace 1005-00-556-4102
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 1005-00-556-4102 5+ Documents (More...)
for $1 a day Upgrade your Account Upgrade 5950-01-390-1312Power Transformer5950013901312 013901312 A10230
A10230 TRANSFORMER,POWER 2 EA NS Request Quotation FedMall Updated Every 15 Minutes 5950-01-390-1312
www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-225-8360 Blind Rivet Plain Nut 5310002258360 002258360 A10230
A10230 TRANSFORMER,POWER 2 EA NS Request Quotation FedMall Updated Every 15 Minutes 5950-01-390-1312
www.nsnlookup.com /fsg-53/fsc-5310/us 5310-00-225-8360 Blind Rivet Plain Nut 5310002258360 002258360 A10230
1963 1005-21-912-3758 Small Arms Cleaning Brush D10138-7RNCC: 3 | RNVC: 2 | DAC: 4 22 Aug 1996 1005-00-556-4102
CAGE 3D531 Jeffrey Alan Manufacturing & Eng Llc in Wales, MI United States
CAGE 4Y985 Marathon Technologies, Inc. in Elk Grove Village, IL United States
A10230 NUT,PLAIN,BLIND RIVET 2 EA NS Request Quotation FedMall Updated Every 15 Minutes 5310-00-225-8360
Restrictions 1005-00-556-4102
1005-00-556-4102 is a Small Arms Cleaning Rod that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 1005-00-556-4102
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 1005-00-556-4102
- US Army (A920)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A181
- Supplementary Receivers:
- AZCTBFBD
- US Coast Guard (C911)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- C085
- US Air Force (FGGC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FGAX
- US Marine Corps (MC40)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- MC51
- US Navy (N9BC)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9CD
- Supplementary Collaborators:
- GBJNJBHXHDGT
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Estonia (WE01)
- Effective Date:
- 1 Jul 2006
- Poland (WP01)
- Effective Date:
- 1 Jul 2003
- Czech Republic (WZ01)
- Effective Date:
- 1 Mar 2015
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Morocco (YP01)
- Effective Date:
- 1 Feb 2009
- Malaysia (YW01)
- Effective Date:
- 1 Jun 1996
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Oct 1993
- Philippines (ZM01)
- Effective Date:
- 1 Feb 2015
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 1005-00-556-4102
- Part Number
- Manufacturer
- Status
- 5564102
- Manufacturer
- 19204 - Army, United States Department Of (Active)
- Primary Buy
- Primary Buy
- RTI-1600
- 39012 - Rti Research Ltd (Active)
- Secondary Buy
- Secondary Buy
- A10230
- U4574 - Fnh Uk Ltd (Active)
- Secondary Buy
- Secondary Buy
- F1232C
- 88001 - United States Postal Service (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 1005005564102
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 1005-556-4102
- A00AM - E.C.A Etablissement Central Des (Active)
- NATO Reference
- NATO Reference
- 1005PL0902408
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
Datasheet 1005-00-556-4102
- Characteristic
- Specifications
- FIIG
- Specifications
- T102-M
- Shaft Material [ANBM]
- Steel
- Handle Type [ADQF]
- Loop
- Section Quantity [AAPN]
- 1
- Cleaning Tip Type [ARJK]
- Swab Holder
- Cleaning Tip Style Designator [CTMW]
- Straight Tip
- Cleaning Tip Attachment Method [ARJM]
- Threaded
- Thread Designator [ARJN]
- 0.164-32Nc-2B
- Thread Length [AASA]
- 0.344 Inches Nominal
- Outside Diameter [ABKV]
- 0.219 Inches Nominal
- Overall Length [ABHP]
- 8.625 Inches Nominal
- End Item Identification [AGAV]
- Grumman Aerospace Corp A10 Aircraft
Weapon Systems (WSDC) 1005-00-556-4102
DLA Procurement Analysis 1005-00-556-4102
- Last Stock Position:
- 91848 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 1005-00-556-4102
Army
- Materiel Category and Inventory Manager:
- J
- Ground Forces Support Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Price Validation Code:
- V
- The current standard price has been validated.
The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
ZOP or Standard price challenges are permissible but must be supported by adequate justification.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Material Identification:
- K
- Reserved
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 1005-00-556-4102
1005-12-170-3901 1005-15-050-9389 1005-33-002-1917 1005-12-341-4371 1005-12-380-2808 1005-15-194-0967 1005-27-008-1158 1005-99-739-0240 1005-00-653-5420 1005-14-310-5976 1005-14-319-9824 1005-27-023-3721 1005-99-962-0261 1005-25-152-7343 1005-16-003-5145 1005-43-000-4735 1005-21-879-2941 1005-01-631-6589
Freight Information 1005-00-556-4102
1005-00-556-4102 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 185710. A Sub NMFC of X. It has a NMFC Description of TOOLS:RODS FIREARM/MACH GUN CLEANG. 1005-00-556-4102 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 91280 which rates the freight between FCL and LCL. 1005-00-556-4102 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 732 for ocean manifesting and military sealift. 1005-00-556-4102 is not classified as a special type of cargo when transported by water. 1005-00-556-4102 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 1005-00-556-4102
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Bare Metal Item
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- MIL-PRF-3150, Medium Preservative Oil, Cold Application
- No Requirement
- No Requirement
- Not Applicable
- --
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Procurement History 1005-00-556-4102 7 Records
- Contract
- Date
- CAGE
- Quantity
- Net Price
- Std Price
- CAGE
- SPE7L416M2022
- 20 Apr 2016
- Subscribe
- 50000
- Subscribe
- Subscribe
- Subscribe
- SPE7L416M0182
- 20 Oct 2015
- Subscribe
- 50000
- Subscribe
- Subscribe
- Subscribe
- SPE7L415M1439P00001
- 12 Feb 2015
- Subscribe
- 15000
- Subscribe
- Subscribe
- Subscribe
- SPE7L015V0292
- 02 Oct 2014
- Subscribe
- 16318
- Subscribe
- Subscribe
- Subscribe
- SPE7L414V0247
- 15 Nov 2013
- Subscribe
- 6774
- Subscribe
- Subscribe
- Subscribe
- SPM7L413V3408
- 12 Apr 2013
- Subscribe
- 5000
- Subscribe
- Subscribe
- Subscribe
- SPM7L413V3340
- 03 Apr 2013
- Subscribe
- 5010
- Subscribe
- Subscribe
- Subscribe
Contracting Technical Data File (CTDF) 1005-00-556-4102 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- F
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
